Assembly And Installation Instructions; Parts List - Modular Closets SHELF TOWER UNIT Assembly And Installation Instructions Manual

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
SHELF TOWER UNIT
1A
BOX 1
A
A
Left Side Panel (Qty 1)
B
Right Side Panel (Qty 1)
BOX 4 - Leg Extension Kit (Optional)
F
B
G C

PARTS LIST

BOX 2
C
FINISHED EDGE
D
FINISHED EDGE
C
D
H
I
L
BOX 3
E
FINISHED EDGE
E
J
FINISHED EDGE
G H
Rear Hanging Cleat (Qty 3)
Set Shelf (Qty 3)
Cam Post (Qty 18)
Camlock (Qty 18)
Screw, Square Drive, 2.5" (Qty 6)
Adjustable Shelf (Qty 2 or 4)
Shelf Pins (Qty 8 or 16)
C
Rear Hanging Cleat (Qty 1)
F
Left Leg Extension (Qty 1)
G
Right Leg Extension (Qty 1)
H
Cam Post (Qty 2)
I
Camlock (Qty 2)
J
K
Wood Dowels (Qty 4)
H
I
L
J
