Assembly And Installation Instructions; Parts List - Modular Closets HANGING TOWER UNIT Assembly And Installation Instructions Manual

ASSEMBLY AND
INSTALLATION INSTRUCTIONS
HANGING TOWER
1A
BOX 1
A
A
Left Side Panel (Qty 1)
B
Right Side Panel (Qty 1)
BOX 5 - Leg Extension Kit (Optional)
F
B
G C

PARTS LIST

BOX 2 / BOX 3
C
FINISHED EDGE
D
FINISHED EDGE
C
Rear Hanging Cleat (Qty 2 each box)
D
Set Shelf (Qty 2 each box)
H
Hanging Rod (Qty1 - Box 2)
I
Rod Bracket (Qty 2 - Box 2)
J
Cam Post (Qty 12 each box)
K
Camlock (Qty 12 each box)
N
Screw, Square Drive, 2.5" (Qty 4 each box)
BOX 4
E
FINISHED EDGE
E
L
FINISHED EDGE
J K
H
Adjustable Shelf (Qty 2)
Shelf Pins (Qty 8)
C
Rear Hanging Cleat (Qty 1)
F
Left Leg Extension (Qty 1)
G
Right Leg Extension (Qty 1)
J
Cam Post (Qty 2)
K
Camlock (Qty 2)
M
M
Wood Dowels (Qty 4)
J
K
N
O
I
L
