ASSEMBLY AND INSTALLATION INSTRUCTIONS
CUBBY TOWER - 18" / 24" / 30"
7
7.1
Determine the mounting location for the unit. The unit can be wall mounted or floor mounted (by installing the Floor
Support Panels as shown in step 6).
7.2
Using a stud finder, locate studs to which the unit will be secured. Mark stud locations with a pencil.
7.3
With the unit positioned at the desired location, level the unit, then drill pilot holes through Rear Hanging Cleats (E),
NOTE: For 18" and 24" units, it is likely that only one stud will pass through the unit. In these cases, use two screws
through each Rear Hanging Cleat.
FLOOR MOUNT
PILOT
HOLES
STUDS
INSTALLATION
WALL MOUNT
12" FROM
FLOOR
E
PILOT
HOLES
E
STUDS
