Analog Input (54)
Variable SNVT
name: type:
nvoAnIn1 Changeable
SNVT_volt
SNVT_amp_mil
SNVT_lev_percent
This variable contains the value allocated to the analog input terminal 54.
This terminal can either be configured as a voltage input (0-10 V) or as a current input (0-20 mA), depending on the setting of switch S 202. The variable
type is changeable with the commissioning tool in order to match the appropriate unit.
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V/mA to par. 6-21
High Current
Analog Input (X30/11)
Variable SNVT
name: type:
nvo101AnIn1 Changeable
SNVT_volt
SNVT_lev_percent
This variable contains the value allocated to the analog input terminal X30/11 of the
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V to par. 6-31
NB!
This variable is available only if the General Purpose I/O option (MCB101) has been installed.
Analog Input (X30/12)
Variable SNVT
name: type:
nvo101AnIn2 Changeable
SNVT_volt
SNVT_lev_percent
This variable contains the value allocated to the analog input terminal X30/12 of the
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V to par. 6-41
NB!
This variable is available only if the General Purpose I/O option (MCB101) has been installed.
Min.
0 V
0 mA
0 %
Min.
0 V
0 %
General Purpose I/O option, MCB101
Min.
0 V
0 %
General Purpose I/O option, MCB101
MG.11.E2.02 - VLT ® is a registered Danfoss trademark
5 Configuration of the system
Value:
Max. Resolution:
10 V 0.1 V
20 mA 0.1 mA
100 % 0,1 %
Terminal 54 High Voltage
or par. 6-23
Value:
Max. Resolution:
10 V 0.1 V
100 % 0,1 %
.
Terminal X30/11 High Voltage
.
Value:
Max. Resolution:
10 V 0.1 V
100 % 0,1 %
.
Terminal X30/12 High Voltage
.
5
