VLT® FC 100 LonWorks
5.2.2 Network variable description - FC VSD Profile - output
Status Word
Variable name:
nvoStatusWord
This variable is a 16-bit word providing status information on the frequency converter. For more information on the status word, please refer to the
Danfoss FC Control Profile
section.
NB!
Please note that in the representation of the Status Word in the LonMaker Browser, the Least Significant Bit (LSB) is to the far left.
Drive Output [%]
Variable SNVT
name: type:
nvoOutputPcnt SNVT_lev_percent
In open loop operation, this variable contains the frequency converter output frequency in percentage, within the reference range.
In closed loop operation, this variable contains the frequency converter feedback signal, within the reference range.
Drive Output [Hz]
Variable SNVT
name: type:
nvoOutputHz SNVT_freq_hz
This variable displays the actual output of the frequency converter motor frequency in Hz.
kWh Counter [kWh]
Variable SNVT
name: type:
nvoDrvEnrg SNVT_elec_kwh_l
This variable contains the power consumption of the motor in kWh measured as a mean value over a one hour period.
SNVT type:
SNVT_state
-163.840 %
Min.
0 Hz
Min.
0 kWh
MG.11.E2.02 - VLT ® is a registered Danfoss trademark
State:
Boolean 1 bit x 16
Value:
Min. Max.
+163.840 %
Value:
Max.
6,500 Hz
Value:
Max.
219,748,364.8 kWh
5 Configuration of the system
Resolution:
0.005 %
Resolution:
1 Hz
Resolution:
1 kWh
5
