5 Configuration of the system
Digital / Relay Outputs
Variable
name:
nviDigitOutput
This variable controls the state of the digital outputs and relays.
A logical 1, indicates that the output is On or active.
A logical 0, indicates that the output is Off or inactive.
Bit 0
Bit 1
Bit 2
5
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9-63
Analog Output (42)
Variable
name:
nviAnOut1
This variable controls the analog output 42, 0-20 mA or 4-20 mA.
In order to control output 42 via LonWorks, par. 6-50
[139] Bus ctrl. 0-20 mA
[140] Bus crtl. 4-20 mA
[141] Bus crtl. 0-20 mA Timeout
[142] Bus crtl. 4-20 mA Timeout
Function:
Bus crtl. 0-20 mA [139]: The output is controlled via bus. In the event of bus timeout, the output level remains unchanged.
Bus crtl. 4-20 mA [140]: The output is controlled via bus. In the event of bus timeout, the output level remains unchanged.
Bus crtl. 0-20 mA [141]: The output is controlled via bus. In the event of bus timeout, the output level is set to the predefined level in par. 6-54
42 Output Timeout Preset
Bus crtl. 4-20 mA [142]: The output is controlled via bus. In the event of bus timeout, the output level is set to the predefined level in par. 6-54
42 Output Timeout Preset
24
SNVT
type:
SNVT_state_64
SNVT
type:
SNVT_lev_percent
Terminal 42 Output
.
.
MG.11.E2.02 - VLT
CC Digital Output Terminal 27
CC Digital Output Terminal 29
GPIO Digital Output Terminal X30/6
GPIO Digital Output Terminal X30/7
CC Relay 1 output terminal
CC Relay 2 output terminal
Option B Relay 1 output terminal
Option B Relay 2 output terminal
Option B Relay 3 output terminal
Reserved for future terminals
Min.:
0 %
must be set to one of the following options:
®
is a registered Danfoss trademark
VLT® FC 100 LonWorks
State:
Boolean 1 bit x 64
Value:
Max.:
Resulution:
100 %
0.01 %
Terminal
Terminal
