5 Configuration of the system

5.3 VSD 6010 Profile

5.3.1 Introduction
The Variable Speed Drive 6010
It describes how to control a variable speed frequency converter.
For example, an air handling unit controller that sends messages to facilitate control of the start/stop and speed reference of the VSD. The VSD will deliver
messages such as the actual frequency converter speed and output current to the controller, operating interfaces and energy management systems.
5
5.3.2 Input Variables
Variable function
Drive speed setpoint
5.3.3 Output Variables
Variable function
Drive speed
Output current
Output voltage
Output power
Running hours
34
profile is a LonMark standardized functional profile.
Variable name
nviDrvSpeedStpt
Variable name SNVT type
nvoDrvSpeed SNVT_lev_percent
nvoDrvCurnt SNVT_amp
nvoDrvVolt SNVT_volt
nvoDrvPwr SNVT_power_kilo
nvoDrvRunHours SNVT_time_hour
MG.11.E2.02 - VLT
SNVT type Profile
SNVT_switch VSD 6010
Profile
VSD 6010
VSD 6010
VSD 6010
VSD 6010
VSD 6010
® is a registered Danfoss trademark
VLT® FC 100 LonWorks
FC 100 parameter
CTW / Reference
FC 100 parameter
16-05
16-14
16-12
16-10
15-01
