Interface configuration

Display
Range
Adr 0 / 3 ... 90
--- /
Adr 1
1.2k ... 115k
8E1
Adr 2 8o1
8n1
FAC = Factory setting;
( ) = Customer setting not changed by factory setting.
7.3 "t" menu

Configuring time settings

Display
Range
t 0 ... 10
30
Setting
FAC Cs
3 (
"---" (
8E1 (
Cs = User setting
Setting
FAC Cs
0
Description
Adr = 0
BMS disabled as well as
Bus-
) Modbus; Isodata enabled
Addr.
with continuous data
output (115k2, 8E1)
"---" : BMS bus (9k6, 7E1)
Baud
) "1.2k" ... "115k" -->
rate
Modbus (variable, var.)
8E1 - 8 data bits
even parity, 1 stop bit
8o1 - 8 data bits
)
odd Parity, 1 stop bit
8n1 - 8 data bits
no parity, 1 stop bit
Description
s Device start up time
