Insulation monitoring device for earth fault detection in unearthed dc systems up to 120 v
Hide thumbs Also See for ISOMETER isoUG425:

Advertisement

Quick Links

Kurzanleitung DE
Quick-start guide EN
ISOMETER® isoUG425
Isolationsüberwachungsgerät für Erdschlusserfassung in ungeerdeten
Gleichspannungsnetzen bis 120 V
Insulation monitoring device for earth fault detection in unearthed
DC systems up to 120 V
isoUG425_D00220_04_Q_DEEN / 11.2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISOMETER isoUG425 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bender ISOMETER isoUG425

  • Page 1 Kurzanleitung DE Quick-start guide EN ISOMETER® isoUG425 Isolationsüberwachungsgerät für Erdschlusserfassung in ungeerdeten Gleichspannungsnetzen bis 120 V Insulation monitoring device for earth fault detection in unearthed DC systems up to 120 V isoUG425_D00220_04_Q_DEEN / 11.2023...
  • Page 2 ISOMETER® isoUG425 ISOMETER® isoUG425 ISOMETER® isoUG425 Isolationsüberwachungsgerät Isolationsüberwachungsgerät Diese Kurzanleitung ersetzt nicht das Handbuch! This quick-start guide does not replace the manual! Kurzanleitung für folgende Geräte Quick-start guide for the following devices Nennspannung / Versorgungsspannung / Handbuch Nr. / Typ/Type Art.-Nr.
  • Page 3: Montage

    ISOMETER® isoUG425 Abmessungen Dimensions 45 70,5 31,1 47,5 74,5 Maßangabe in mm Dimensions in mm Montage Mounting Beachten Sie den Mindestabstand zu benachbar- Consider a minimum distance to adjacent ten Geräten: devices: Seiten 0 mm, oben 20 mm, unten 20 mm! sides 0 mm;...
  • Page 4: Wiring Diagram

    ISOMETER® isoUG425 Anschlussbild Wiring diagram E KE Test / Reset MENU COM465IP RS-485 Klemme / Anschlüsse Connections Terminal Anschluss an die Versorgungsspannung U über Connection to the supply voltage U via a fuse: Schmelzsicherung: A1, A2 If supplied from an IT system, both lines have to be protected Bei Versorgung aus IT-System beide Leitungen absichern.
  • Page 5: Control Panel

    ISOMETER® isoUG425 Bedienfeld Control panel Funktion Gerätefront/Device front Element Function grün - On green - On gelb - Vorwarnung yellow - Pre-warning gelb - Alarm yellow - Alarm Aufwärts-Taste Up button Test-Taste (> 1,5 s drücken) Test button (press > 1.5 s) Bei gedrückter Test-Taste werden die By pressing and holding the test button, Display-Elemente angezeigt.
  • Page 6: Menü-Übersicht

    ISOMETER® isoUG425 Menü-Übersicht Menu overview Messwertanzeige Menüauswahl Parametereingabe Measurement display Menu selection Parameter selection > < 1.5 s > > 1.5 s 1.5 s . . . < t > 5 Min. < > 1.5 s R [k ] C [µF] U L1 L2 [V] U L1 [V] <...
  • Page 7: Technische Daten

    ISOMETER® isoUG425 Technische Daten Technical data ()* = Werkseinstellung ()* = Factory settings Isolationskoordination nach IEC 60664-1/IEC 60664-3 Insulation coordination acc. to IEC 60664-1/IEC 60664-3 Bemessungsspannung ..............400 V Rated voltage ................. 400 V Überspannungskategorie ..............III Overvoltage category ................III Versorgungsspannung Supply voltage Versorgungsspannung U ......
  • Page 8: Eu-Konformitätserklärung

    Alle Rechte vorbehalten. 35305 Grünberg Nachdruck und Vervielfältigung nur mit Germany Genehmigung des Herausgebers. © Bender GmbH & Co. KG, Germany Subject to change! The specified Tel.: +49 6401 807-0 All rights reserved. standards take into account the edition info@bender.de...
