Intended Use - Bender ISOMETER isoUG425 Quick Start Manual

ISOMETER® isoUG425
Insulation monitoring device for unearthed
DC systems (IT systems) up to 120 V
Software version: D476 V2.xx
This operating manual is designed for electrically skilled persons working in
electrical engineering and electronics! It does not replace the operating ma-
nual. Make sure that the personnel has read this manual and understood all
instructions relating to safety.
The manual can be found at:
www.bender.de/en/service-support/downloads

1. Intended use

The ISOMETER® monitors the asymmetrical insulation resistance R
arthed DC main circuits (IT systems) with nominal system voltages of
DC 12. . .120 V. The maximum permissible system leakage capacitance C
50 uF
isoUG425_D00220_02_Q_DEEN / 05.2018
In the case of an insulation fault on a power conductor, the
measured residual voltage is evaluated to determine the
insulation resistance R
can be detected using the passive measurement method
employed in this ISOMETER®. Equally large insulation faults
between the positive and negative power conductors to
earth (i.e. symmetrical faults) are not detected .
In the event of an alarm message, the insulation fault should
be eliminated as quickly as possible.
. Only asymmetrical insulation faults
F
of une-
F
is
e
19
