VLT AQUA High Power Operation Instructions
0-20 Display Line 1.1 Small
Option:
[0]
[37]
[38]
[39]
[89]
[953]
[1005] Readout Transmit Er-
[1006] Readout Receive Er-
[1007] Readout
[1013] Warning Parameter
[1115] LON Warning Word
[1117] XIF Revision
[1118] LON Works Revision
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%] One or more warnings in a Hex code
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
Function:
Select a variable for display in line 1, left position.
None No display value selected
Display Text 1 Present control word
Display Text 2 Enables an individual text string to be written, for display in the
LCP or to be read via serial communication.
Display Text 3 Enables an individual text string to be written, for display in the
LCP or to be read via serial communication.
Date and Time Read- Displays the current date and time.
out
Profibus Warning Displays Profibus communication warnings.
Word
View the number of CAN control transmission errors since the
ror Counter last power-up.
View the number of CAN control receipt errors since the last
ror Counter power-up.
Bus Off View the number of Bus Off events since the last power-up.
Counter
View a DeviceNet-specific warning word. One separate bit is as-
signed to every warning.
Shows the LON-specific warnings.
Shows the version of the external interface file of the Neuron C
chip on the LON option.
Shows the software version of the application program of the
Neuron C chip on the LON option.
View the number of running hours of the motor.
View the mains power consumption in kWh.
View the Control Word sent from the frequency converter via
the serial communication port in hex code.
* Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./
catch up and slow-down) in selected unit.
Total reference (sum of digital/analog/preset/bus/freeze ref./
catch up and slow-down) in percent.
Present status word
View the user-defined readouts as defined in par. 0-30, 0-31
and 0-32.
Actual power consumed by the motor in kW.
Actual power consumed by the motor in HP.
Voltage supplied to the motor.
®
