6.6 REMOTE MONITORING OF OUTPUT VOLTAGE AND CURRENT

The J1 connector, located on the rear panel provides analog signals for monitoring the Output
Voltage and Output Current. Selection of the voltage range between 0-5V or 0-10V is made by
setup switch SW1-4. The monitoring signals represent 0 to 100% of the power supply Output
Voltage and Output Current. The monitor outputs have 500 ohm series output resistance. Ensure
that the sensing circuit has an input resistance of greater than 500 Kohm or accuracy will be re-
duced.
Refer to Table 6-5 for the required J1 connection, SW1-4 setting and monitoring voltage range.
Signal
name
VMON
IMON
VMON
IMON
Notes:
1. Radiated emissions, RCC requirements: FCC requirements for radiated emissions; use a
2. Front panel encoders operation:
3. Front panel PREV button:
4. Communication:
Signal function
Signal (+)
Vout monitor
Iout monitor
Vout monitor
Iout monitor
Table 6-5 Monitoring signals setting
shielded cable for the analog control signals. If using
unshielded cable, attach an EMI ferrite suppressor to
the cable, as close as possible to the power supply.
In Remote analog mode, the output voltage and cur-
rent can't be set by the VOLTAGE and CURRENT
encoders.
Use the PREV button to display the Output Voltage
and Current setting, as defined by the encoders or
digital communication.
In Remote analog mode, all power supply parame-
ters can be programmed and readback via the
communication port, except the Output Voltage and
Current setting.
83-507-5002 Rev. B
J1 connection
Return (-)
J1-11
J1-12
J1-24
J1-11
J1-12
J1-24
49
Range SW1-4
0-5V Down
0-10V Up
