CHAPTER 4 FRONT AND REAR PANEL CONTROLS AND CONNECTORS

4.1 INTRODUCTION

TM
The Genesys Power Supply series has a full set of controls, indicators and connectors that al-
low the user to easily setup and operate the unit. Before starting to operate the unit, please read
the following Sections for explanation of the functions of the controls and connectors terminals.
-Section 4.2: Front Panel Controls and Indicators.
-Section 4.3: Rear Panel Connections and Controls.

4.2 FRONT PANEL CONTROLS AND INDICATORS

See Fig.4-1 to review the controls, indicators and meters located on the power supply front panel.
POWER
19
Table 4-1: Front Panel controls and indicators
Number Control/Indicator
1 VOLTAGE
control
2 VOLTAGE
indicator
3 VOLTAGE
display
2 3
1
VOLTAGE
DC VOLTS
PREV/
ALARM FINE
16 14
18
15
17
Fig.4-1: Front panel controls and indicators
Description
High resolution rotary encoder for adjusting the Out-
put Voltage. Also adjusts the OVP/UVL levels and
selects the Address
Green LED, lights for constant-Voltage mode opera-
tion.
4 digit, 7-segment LED display. Normally displays
the Output Voltage. When the PREV button is
pressed, the display indicates the programmed set-
ting of the Output Voltage. When the OVP/UVL but-
ton is pressed, the Voltage display indicates the
OVP/UVL setting.
83-507-5002 Rev. B
4
OVP
REM/LOC OUT
UVL FOLD
11
13 9
12
27
6
5
CURRENT
DC AMPS
7
8
10
Section
5.2.1
5.3.1
5.4.1
7.2.2
