USER MANUAL FOR
GENESYS
Programmable DC Power Supplies
Document: 83-532-002 Rev J
TDK-Lambda Americas Inc.
Programmable & High Voltage
405 Essex Road, Neptune, NJ 07753
Tel:
Fax:
www.us.tdk-lambda.com/hp
10KW/15KW
TM
+1.732.795.4100
+1.732.922.9334
