Terminals 12, 22 and 23 of J1 are connected internally to

the negative sense (-S) potential of the power supply. Do

not attempt to bias any of these terminals relative to the

negative sense. Use the Isolated Programming interface

option to allow control from a programming source at a dif-

ferent potential relative to the power supply negative.

To prevent ground loops and to maintain power supply isola-

tion when programming from J1, use an ungrounded pro-

gramming source.

There is a potential shock hazard at the output when using a

power supply with rated output greater than 40V. Use wires

with minimum insulation rating equivalent to the maximum

output voltage of the power supply.

CAUTION

WARNING

83-507-5002 Rev. B
