Table 4-3: SW1 Positions Functions
Position
Output Voltage
SW1-1
remote analog programming
Output Current
SW1-2
remote analog programming
Programming Range Select
SW1-3
(Remote voltage/resistive)
Output Voltage and
SW1-4
Current Monitoring Range
SW1-5
Shut-Off Logic select
SW1-6
RS232/485 select
Outp ut Voltage
SW1-7
Resistive Programming
Output Current
SW1-8
Resistive Programming
SW1-9
Enable/Disable control

4.4.2 Resetting the SW1 switch

Before making any changes to the SW1 switch setting, disable the power supply output by press-
ing the front panel OUT button. Ensure that the Output Voltage falls to zero and the OUT LED is
Off. Then use any small flat-bladed screwdriver to change the SW1 switch setting.

4.5 REAR PANEL J1 PROGRAMMING AND MONITORING CONNECTOR

The J1 Programming and Monitoring connector is a DB25 subminiature connector located on the
power supply rear panel. Refer to Table 4-4 for description of the connector functions. The power
supply default configuration is Local operation, which does not require connections to J1. For
remote operation using J1 signals, use the plug provided with power supply (or equivalent type).
It is essential to use a plastic body plug to conform to Safety Agency requirements. If a shield is
required for the J1 wires, connect the shield to a power supply chassis ground screw.

4.5.1 Making J1 connections

-J1 Connector type: AMP, P/N:747461-3
-J1 plug description: AMP, P/N:745211-2
-Wire dimension range: AWG26-22
-Manual Pistol grip tool:
-Insertion/Extraction tool: AMP, 91232-1
Before making any connection, turn the AC On/Off switch to the Off position and wait until the
front panel display has turned Off.
Function
Handle:AMP, P/N:58074-1
Head:AMP, P/N:58063-2
83-507-5002 Rev. B
DOWN (Factory default)
Output Voltage
programmed by
Front Panel
Output Current
programmed by Front
Panel
0-5V/(0-5Kohm)
0-5V
Off: Low (0-0.6V) or Short
On: High (2-15V) or Open
RS232 interface
Output Voltage
programmed by Front
Panel
Output Current
programmed by Front
Panel
Rear panel
Enable/Disable control is
not Active
31
UP
Output Voltage
programmed by remote
analog voltage
Output Current
programmed by remote
analog voltage
0-10V/(0-10Kohm)
0-10V
Off: Low (2-15V) or Open
On: High (0-0.6V) or Short
RS485 interface
Output Voltage
programmed by
external resistor
Output Current
programmed by external
resistor
Rear panel
Enable/Disable con trol
is Active
