CHAPTER 2 SPECIFICATIONS

2.1 OUTPUT RATING

MODEL
1.Rated output voltage (*1)
2.Rated output current 750W (*2)
3.Rated output power 750W
MODEL
1.Rated output voltage (*1)
2.Rated Output Current 1500W (*2)
3.Rated output power 1500W

2.2 INPUT CHARACTERISTICS

1. Input voltage/freq. (*3)
2. Input current (at 100/200Vac)
3. Power Factor
4. 750W models Efficiency (*4)
5. 1500W models Efficiency (*4)
6. Inrush current at 100/200V

2.3 CONSTANT VOLTAGE MODE

1. Max.Line regulation (*5)
2. Max.Load regulation (*6)
3. Ripple and noise (p-p,20MHz) (*10)
4. Ripple r.m.s., 5Hz~1MHz (*10)
5. Temperature coefficient
6. Temperature drift
7. Rem. Sense compensation/wire
8. Up-prog. Response time 0~Vomax (*9)
9. Down-prog. Response time: Full load
No load
10. Transient response time
11. Hold-up time

2.4 CONSTANT CURRENT MODE

1. Max.line regulation (*5)
2. Max.load regulation (*7)
3. Ripple r.m.s. 5Hz~1MHz.750W (*8)
1500W (*8)
4. Temperature coefficient
5. Temperature drift
2.5 ANALOG PROGRAMMING AND MONITORING
1.Vout voltage programming
2. Iout voltage programming
3. Vout resistor progrmming
4. Iout resistor programming
5. On/off control
6. Output current monitor
7. Output voltage monitor
8. Power supply OK signal
9. Parallel operation
10. Series operation
11. CV/CC inicator
12. Enable/Disable
13. Local/Remote analog control
14. Local/remote analog indicator
GEN 6-100 8-90 12.5-60
V 6 8 12.5
A 100 90 60
W 600 720 750
GEN 6-200 8-180 12.5-120
V 6 8 12.5
A 200 180 120
W 1200 1440 1500
V 6 8 12.5
– 85~265Vac continuous, 47-63Hz, single phase.
A 10.5/5 for 750W model, 21/11 for 1500W models.
– 0.99@100/200Vac, rated output power.
% 76/78 77/80 81/84
% 77/79 78/81 82/85
A Less than 25A for 750W models, 50A for 1500W models.
V 6 8 12.5
0.01% of rated output voltage +2mV
–
0.01% of rated output voltage +2mV
–
mV 60 60 60
mV 8 8 8
PPM/°C 100PPM/°C of rated output voltage, following 30 min utes warm up
0.05% of rated Vout over 8hrs interval following 30 minutes warm-up. Constant line, load & temp.
–
V 1 1 1
mS
mS 10 50
500 600 700
mS Time for the output voltage to recover within 0.5% of its rated output for a load change 10~90% of rated
output current.
Output set-point: 10~100%.
Less than 1mS for models up to and including 100V; 2mS for models above 100V.
mS More than 20mS, 100Vac, rated output power.
V 6 8 12.5
– 0.01% of rated output voltage +2mA
– 0.02% of rated output current +5mA
mA 200 180 120
mA 400 360 240
100PPM/°C from rated output current, following 30 m inutes warm-up.
PPM/°C
– 0.05% of rated lout over 8hrs interval following 30 minutes warm-up. Constant line, load & temp.
– 0~100%, 0~5V or 0~10V, user select. Accuracy and linearity; +/-0.5% of rated Vout.
– 0~100%, 0~5V or 0~10V, user select. Accuracy and linearity; +/-1% of rated Iout.
0~100%, 0~5/10Kohm full scale, user select. Accuracy and linearity: +/-1% of rated Vout.
–
– 0~100%, 0~5/10Kohm full scale, user select. Accuracy and linearity: +/-1.5% of rated Iout.
– By electrical Voltage: 0~0.6V/2~15V or dry contact, user selectable logic.
– 0~5V or 0~10V, user selectable. Accuracy: 1%
– 0~5V or 0~10V, user selectable. Accuracy: 1%
– 4~5V-OK, 0V-Fail, 500ohm series resistance.
– Possible, up to 4 units in master/slave mode with single wire current balance connection.
– Possible (with external diodes), up to 2 units.
– CV: TTL high (4~5V), source current: 10mA, CC: TTL low (0-0.6V). Sink current: 10mA .
– Dry contact. Open: off, Short: on. Max. voltage at Enable/Disable in: 6V.
By electrical signal or Open/Short: 0~0.6V or short: Remote, 4~5V or open: Local.
–
– Open collector. Local: Open, Remote: On. Maximum voltage: 30V, maximum sink current: 5mA.
9
83-507-5002 Rev. B
20-38 30-25 40-19 – 60-12.5
20 30 40 – 60
38 25 19 – 12.5
760 750 760 – 750
20-76 30-50 40-38 50-30 60-25
20 30 40 50 60
76 50 38 30 25
1520 1500 1520 1500 1500
20 30 40 50 60
82/85 82/85 83/87 83/87 83/87
83/86 83/86 84/88 84/88 84/88
20 30 40 50 60
60 60 60 60 60
8 8 8 8 8
1 1.5 2 2 3
80
80
800 900 1000 1100 1100
20 30 40 50 60
76 63 48 – 38
152 125 95 75 75
80-9.5 100-7.5 150-5 300-2.5 600-1.3
80 100 150 300 600
8.5 7.5 5 2.5 1.3
760 750 750 750 780
80-19 100-15 150-10 300-5 600-2.6
80 100 150 300 600
19 15 10 5 2.6
1520 1500 1500 1500 1560
80 100 150 300 600
83/87 83/87 83/87 83/87 83/87
84/88 84/88 84/88 84/88 84/88
80 100 150 300 600
80 80 100 150 300
8 8 10 25 60
4 5 5 5 5
150 250
150 250
1200 1500 2000 2500 4000
80 100 150 300 600
29 23 18 13 8
57 45 35 25 12
