BATTERY
Battery Use
•
DO NOT allow the batteries to come into contact with any kind of liquid. DO NOT leave batteries out in the
rain or near a source of moisture. DO NOT drop the battery into water. If the inside of the battery comes into
contact with water, corrosion may occur, potentially resulting in the battery catching on fire, and may even
lead to an explosion.
•
Never use non-XDynamics batteries. Go to www.xdynamics.com to purchase new batteries. XDynamics takes
no responsibility for any damage caused by non-XDynamics batteries.
•
Never use or charge swollen, leaky, or damaged batteries. If your batteries are abnormal, contact XDynamics
or an XDynamics authorized dealer for further assistance.
•
Never install or remove the battery from the aircraft when it is turned on. DO NOT insert or remove batteries
if the plastic cover has been torn or compromised in any way.
•
The battery should be used in temperatures from 32
o
environments above 50 C can lead to a fire or explosion. Use of battery below 32
permanent damage
•
DO NOT use the battery in strong electrostatic or electromagnetic environments. Otherwise, the battery
control board may malfunction and cause a serious accident during flight.
•
Never disassemble or pierce the battery in any way or the battery may leak, catch fire, or explode.
•
Electrolytes in the battery are highly corrosive. If any electrolytes make contact with your skin or eyes,
immediately wash the affected area with fresh running water for at least 15 minutes, and then see a doctor
immediately.
•
DO NOT use the battery if it was involved in a crash or heavy impact.
•
If the battery falls into water with the aircraft during flight, take it out immediately and put it in a safe and
open area. Maintain a safe distance from the battery until it is completely dry. Never use the battery again,
and dispose of the battery properly as described in the Battery Disposal section below. DO NOT heat
batteries. Put out any battery fire using sand or a dry powder fire extinguisher
•
DO NOT put batteries in a microwave oven or in a pressurized container.
•
DO NOT place loose battery cells on any conductive surface, such as a metal table.
•
DO NOT put the loose cells in a pocket, bag or drawer where they may short-circuit against other items or
where the battery terminals could be pressed against each other.
•
DO NOT drop or strike batteries. DO NOT place heavy objects on the batteries or charger. Avoid dropping
batteries.
•
Clean battery terminals with a clean, dry cloth.
76
o o o o
F to 104 F (0 C to 40 C). Use of the battery in
o o
F (0 C) can lead to
•
Before carrying the Intelligent Flight Battery onto an airplane, the battery must first be discharged to below
5%. Only discharge the battery in a fireproof location.
Battery Use
•
Make sure the batteries are fully charged before each flight.
•
Land the aircraft immediately when low battery levels are activated.
Battery Charging
•
The Intelligent Flight Battery is designed to stop charging when it is full. However it is a good practice to
monitor the charging progress and disconnect the batteries when fully charged.
•
Ensure the Intelligent Flight Battery is turned off at all times during charging.
Battery Storage
•
Discharge the battery to 40%-65% if it will NOT be used for 10 days or more. This can greatly extend the
battery life.
•
The battery automatically discharges to below 65% when it is idle for more than 10 days to prevent it from
swelling. It takes approximately 3 days to discharge the battery to 65%. It is normal that you may feel
moderate heat emitting from the battery during the discharge process.
•
DO NOT store the battery for an extended period after fully discharging it. Doing so may over-discharge the
battery and cause irreparable battery cell damage.
•
The battery will enter hibernation mode if depleted and stored for a long period.
•
Recharge the battery to bring it out of hibernation.
•
Remove batteries from the aircraft when stored for an extended period.
Battery Disposal
•
If the power on/off button on the Intelligent Flight Battery is disabled and the battery cannot be fully
discharged, please contact a professional battery disposal/recycling agent for further assistance.
Battery Maintenance
•
Never over-discharge, as this may lead to battery cell damage.
•
Battery life may be reduced if not used for a long time.
•
Fully charge and discharge the battery at least once every 3 months to maintain battery health.
Travel Notice
•
Store Intelligent Flight Batteries in a ventilated location.
Evolve User Manual V1.0 by XDynamics Limited 77
