TURNING ON/OFF AIRCRAFT BATTERY

Turning the Battery On When not Plugged into the aircraft
Press and release the battery switch then press again and hold battery switch until the XDynamics logo runs across the
screen.
Note: Never short out any of the pins of the battery or try to connect to any other equipment other than the Evolve
aircraft and the supplied charger.
Turning the Battery Off When not Plugged into the aircraft
Press and release the battery switch then press again and hold battery switch until the XDynamics logo runs across the
screen.
Note: Never short out any of the pins of the battery or try to connect to any other equipment other than the Evolve
aircraft and the supplied charger.
15%
20
100%

AIRCRAFT LED INDICATORS

The aircraft LED indicators are located under each motor and at the rear of the aircraft. The LED indicates the current state
of the aircraft. See diagrams below for indications.
LED Powering Up / Arming Flight Control
(Green / Yellow Alternating Fast Blinking LED)
Initializing / Waiting for RC Signal
(Blinking Red LED)
Error State
(Solid Red LED) - Refer to Troubleshooting Section
Evolve User Manual V1.0 by XDynamics Limited 21
