XDynamics EVOLVE User Manual page 39

REMOTE CONTROLLER
ITEM
Sensors
Operating Temperature
Battery
Transmitter Power (EIRP)
Operating Voltage
Dimensions
Weight (including battery)
74
SPECIFICATION
Magnetometer
Accelerometer
Three-axis gyroscope
Proximity Detector
Microphone
32°F - 104°F (0 - 40°C)
6000 mAh Li-Po 3S
FCC: 20 dBm (not released)
11.1V @ 4A (max)
6.7in(D) x 4in(H) x 9in(W)
(171 x 105 x 230 mm)
3.40 lbs (1.55kg)
AIRCRAFT BATTERY
ITEM
Capacity
Voltage
Battery Type
Energy
Net Weight
Dimensions
Operating Temperature
Max Charging Voltage
GROUND STATION BATTERY
ITEM
Capacity
Voltage
Battery Type
Energy
Net Weight
Dimensions
Operating Temperature
Max Charging Voltage
SPECIFICATION
6700 mAh 4 Cell LiPo
14.8V
Lithium-ion Polymer
99.16 Wh
<650g
190mm*67.5mm*40mm
0 to 40°C
17.4V
SPECIFICATION
6000 mAh Li-Po 3S
11.1V @ 4A(max)
Lithium-ion Polymer
66 Wh
<440 g
156.7 mm*68.4 mm*40.7 mm
0 to 40°C
18V
Evolve User Manual V1.0 by XDynamics Limited 75
