XDynamics EVOLVE User Manual page 13

AIRCRAFT LED INDICATORS
The aircraft LED indicators are located under each motor and at the rear of the aircraft. The LED indicates the current state
of the aircraft. See diagrams below for indications.
Ready for Flight (GPS Mode)
(Solid Blue LED) – Ready for Smart Pilot App Launch
GPS Ready (Can be flown in GPS Mode)
(Solid Green LED) - Sets home position
Normal Flight Mode
(Red Front / Blue Rear Solid LED) - All systems functional
22
AIRCRAFT LED INDICATORS
The aircraft LED indicators are located under each motor and at the rear of the aircraft. The LED indicates the current state
of the aircraft. See diagrams below for indications.
Landing Mode
(Red Front / Green Rear Solid LED) – Make sure landing zone is clear
Malfunction During Flight
(Consult smart pilot / troubleshooting for more details)
If the 'Malfunctioning During Flight' LED warning is showing land aircraft immediately.
Evolve User Manual V1.0 by XDynamics Limited 23
