AIRCRAFT CALIBRATION

Accelerometer Calibration Procedures
Please note that the aircraft calibration procedures are subject to change. Always follow the procedures indicated in
the Ground Station. Please ensure all firmware is up to date and follow on screen instructions if any variance from the
instructions outlined below.
To calibrate the accelerometer follow these steps
1. For safety reasons, please remove the propellers from the aircraft.
2. Make sure the GS and aircraft are powered on and connected.
3. Navigate to the accelerometer calibration page on the smart pilot APP
(Settings > General > Sensor > Accelerometer)
.
4. Press " OK " on the accelerometer calibration page.
5. Ensure that the aircraft is on a levelled surface and press "next".
6. Follow the on screen instructions for aircraft placement and push "next" when prompted.
7. Once complete, the APP will indicate a failed or successful calibration.
8. If failed switch off the aircraft and controller power and restart at Step 1.
Accelerometer calibration is only required when requested by the Smart Pilot System.
58
AIRCRAFT CALIBRATION
Accelerometer Calibration Procedures
Evolve User Manual V1.0 by XDynamics Limited 59
