PRODUCT SPECIFICATION

GIMBAL
ITEM
Controllable Range
Gimbal Accuracy
Stabilization
Power Output
Voltage
Output Current
Net Weight
Dimensions
Operating Temperature
Input Voltage
CAMERA
ITEM
CMOS Sensor
Lens
ISO Range
Shutter Speed
Max Photo Resolution
Video Resolution
Max Video Bit Rate
Photo File Formats
Video File Formats
Supported SD Card Types
Connectivity
Weight (including RTC battery)
Dimensions
Encoding
72
SPECIFICATION
Pitch -90° to +10°
Static stability: ±0.01°, motion stability: ±0.2°
3-axis (pitch, roll, yaw)
120W
18 V
6.6A
663g
190mm*67.5mm*40mm
0 to 40°C
110V – 240V a.c. 50Hz/60Hz
SPECIFICATION
Sony 1/2.3" CMOS, Effective pixels:12.4M
FOV: 94 Degree
21mm, f/2.8, focus at infinite
ISO 100-3200
1/8000s – 1s
4000 x 3000 ( 4 : 3 )
3840 x 2160 ( 16 : 9 )
4K: 3840 x 2160 @ 30 fps / 25 fps
FHD: 1920 x 1080 @ 120 fps / 60 fps / 30 fps
HD: 1280 x 720 @ 240 fps / 120 fps / 60 fps / 30 fps
60Mbit/s
JPEG, DNG
MP4, MOV
Micro SD (SD/SDHC/SDXC) / Max. 64GB
Micro USB 2.0
4.2 oz (120 g)
2.28in x 1.96in x 2.09in (58mm x 50mm x 53mm)
H.264, H.265
REMOTE CONTROLLER
ITEM
Processor
Operating System
Memory
Internal Storage
Supported SD Card Types
Upper Display (View Finder)
Lower Display (Console)
Embedded Camera
R/C & Telemetry Operating Frequency
Max Transmission Distance
Live View Working Frequency
Max Live View Distance
Live View Quality
Live View Transmission Latency
Wireless Connectivity
Peripheral Connectors
SPECIFICATION
Quad Core 2.0GHz 64-bit CPU+ PowerVR GPU
Android 6.0
4GB DDR3
64GB eMMC
Micro SD (SD/SDHC/SDXC) / Max. 64GB
7" 720p Screen
Anti-reflective Coating
Luminance: 600 cd/m2
5" 1080p Multi-Touch Screen
Anti-reflective Coating
Luminance: cd/m2
5MP Front Camera
2.4-2.47GHz
1 km, FCC Compliant, unobstructed and no interference
5.1-5.8GHz
3280ft , FCC Compliant, unobstructed and no interference
1080p @ 60 fps
<10ms
Bluetooth 2.1 EDR
4.0 BLE Wi-Fi (802.11b/g/n/ac)
Miracast & DLNA support
USB 3.0 OTG x 1
USB 3.0 Host x 1
Micro HDMI-out x 1
Microphone-in jack x 1
Headphone-out jack x 1
SD Card Slot x 1
DC-in x 1
