MAP PRELOADING (OFFLINE MAP)

To ensure that the map can be displayed outdoor without network, Smart Pilot System offers the offline map download
feature. Follow the steps below to download the map.
1. Connect Ground Station to WiFi internet connection with download capabilities
2. Navigate to the Smart Pilot System Offline Map Page
3. Tap "+" to create a new offline map area
4. Search for plane or address
5. Drag and pinch the map to the designated area
6. Tap Download to start downloading
7. Smart Pilot System will indicate the download progress
44
(Setting > Map > Offline Map)

RUN WAYPOINT PLAN

Setting Waypoints
To execute the waypoints path, select Smart Mode by choosing the right position on the flight mode switch and then
choose waypoint mode and follow the steps outlined below. Once the plan has been selected and completed, the aircraft
will hover or return to home (RTH) from last waypoint. Auto mode can be cancelled any time by switching the flight mode
switch to the left for GPS mode. The pilot has full control of the position and yaw angle of the aircraft during auto flight.
To execute the plan, you may enter the Fly page by following these steps:
1. Navigate to the Smart Pilot System Fly Page.
2. Tap the Smart GPS Button and select Waypoints.
3. Select the Fly and Point.
4. Fly the aircraft to the interest point and tap C1 to record.
5. Tap "Start" to execute.
