PREPARE THE GROUND STATION

Remove the battery by sliding the battery mechanical latches and pulling the battery out of the aircraft.
See diagram for battery installation below
Steps for preparing the remote controller:
1. First ensure the battery is turned OFF.
2. Slide the latch to the right to disengage the lock.
3. Remove by firmly gripping and pulling the battery from the Ground Station.
36

REMOTE CONTROLLER

Charging the Ground Station battery
The Ground Station battery can be charged with the supplied battery charger whilst inserted into the Ground Station's
main housing.
Follow the steps below to charge the Ground Station battery:
1. Plug in power supply to wall socket power supply.
2. Plug silver round connector into the remote controller.
3. When the LED indicator on the GS turns off battery is fully charged.
Please note the Ground Station battery can also be charged simultaneously with the Evolve aircraft battery.
