Texas Instruments TMS320C6000 Reference Manual page 215

Table Continued
(RW) HMCBSP_XCER_XCEA15
(RW) HMCBSP_XCER_XCEB0
(RW) HMCBSP_XCER_XCEB1
(RW) HMCBSP_XCER_XCEB2
(RW) HMCBSP_XCER_XCEB3
(RW) HMCBSP_XCER_XCEB4
(RW) HMCBSP_XCER_XCEB5
(RW) HMCBSP_XCER_XCEB6
(RW) HMCBSP_XCER_XCEB7
(RW) HMCBSP_XCER_XCEB8
(RW) HMCBSP_XCER_XCEB9
(RW) HMCBSP_XCER_XCEB10
(RW) HMCBSP_XCER_XCEB11
(RW) HMCBSP_XCER_XCEB12
(RW) HMCBSP_XCER_XCEB13
(RW) HMCBSP_XCER_XCEB14
(RW) HMCBSP_XCER_XCEB15
* only on devices with three or more serial ports
5.9.10
HMCBSP_PCR
(RW) HMCBSP_PCR0
(RW) HMCBSP_PCR1
(RW) HMCBSP_PCR2*
Fields
(RW) HMCBSP_PCR_CLKRP
(RW) HMCBSP_PCR_CLKXP
(RW) HMCBSP_PCR_FSRP
(RW) HMCBSP_PCR_FSXP
(R)
(RW) HMCBSP_PCR_DXSTAT
(RW) HMCBSP_PCR_CLKSSTAT
(RW) HMCBSP_PCR_CLKRM
(RW) HMCBSP_PCR_CLKXM
(RW) HMCBSP_PCR_FSRM
(RW) HMCBSP_PCR_FSXM
pin control register
HMCBSP_PCR_DRSTAT
enable element 15 in partition A
enable element 0 in partition B
enable element 1 in partition B
enable element 2 in partition B
enable element 3 in partition B
enable element 4 in partition B
enable element 5 in partition B
enable element 6 in partition B
enable element 7 in partition B
enable element 8 in partition B
enable element 9 in partition B
enable element 10 in partition B
enable element 11 in partition B
enable element 12 in partition B
enable element 13 in partition B
enable element 14 in partition B
enable element 15 in partition B
receive clock polarity
transmit clock polarity
receive frame sync polarity
transmit frame sync polarity
DR pin status
DX pin status
CLKS pin status
receiver clock mode
transmitter clock mode
receive frame sync mode
transmit frame sync mode
HMCBSP
HAL Reference 5-39
