MCBSP
Return Value
4-96
Transmit frame sync polarity:
fsxp
MCBSP_PCR_FSXP_ACTIVEHIGH
MCBSP_PCR_FSXP_ACTIVELOW
DX pin status:
dxstat
MCBSP_PCR_DXSTAT_0
MCBSP_PCR_DXSTAT_1
CLKS pin status:
clksstat
MCBSP_PCR_CLKSSTAT_0
MCBSP_PCR_CLKSSTAT_1
Receiver clock mode:
clkrm
MCBSP_PCR_CLKRM_INPUT
MCBSP_PCR_CLKRM_OUTPUT
Transmitter clock mode:
clkxm
MCBSP_PCR_CLKXM_INPUT
MCBSP_PCR_CLKXM_OUTPUT
Receive frame sync mode:
fsrm
MCBSP_PCR_FSRM_EXTERNAL
MCBSP_PCR_FSRM_INTERNAL
Transmit frame sync mode:
fsxm
MCBSP_PCR_FSXM_EXTERNAL
MCBSP_PCR_FSXM_INTERNAL
Receiver general purpose IO mode:
rioen
MCBSP_PCR_RIOEN_SP
MCBSP_PCR_RIOEN_GPIO
Transmitter general purpose IO mode:
xioen
MCBSP_PCR_XIOEN_SP
MCBSP_PCR_XIOEN_GPIO
Constructed register value
PCR Value
