FC100 Series User Manaul

Group P8: Advanced application parameters

P800

Advanced application parameter lock

Setting Range:0~1
Explanation:
If P800 is set to 0,you can not use the advanced parameters.
P801

System 50Hz/60Hz selection

Setting Range:0~1
Explanation:
50Hz/60Hz system could be set via the parameter according the condition of
electric network.
P802

constant and variable torque selection

Setting Range:0~1
Explanation:
For fan and pump load, you can select "variable torque" for better energy
saving.
P803
Overvoltage protection setting
Setting Range:760~820
P803 sets DC-bus overvoltage protection level. This function could be used to
avoid overvoltage protection during deceleration.
P804
Undervoltage protection setting
Setting Range:380~450
P804 sets voltage protection level.
If the input voltage is low, inverter is easy to trip for undervoltage. This function
could be used to avoid inverter protection undervoltage
P805
Over temperature protection setting
Setting Range:40~120
P805 sets the over temperature protection level of inverter. In high temperature
environment, the protection level could be improved appropriately, to guarantee
the normal running of inverter. However, too high setting value will result in
IGBT damage, so the only solution is to improve the effect of heat elimination,
so as to achieve the goal of cooling down
0: Lock 1: Unlock
0: 50HZ 1: 60HZ
0: Constant torque 1: Variable torque
Chapter 6 Description of parameter setting
Factory Setting:Change
Factory Setting:Change
Factory Setting:Change
97
Factory Setting:1
Unit:1
Factory Setting:0
Unit:1
Factory Setting:0
Unit:1
Unit:1
Unit:1
Unit:1
6
