FC100 Series User Manaul
P425

Reaching frequency 1

Setting Range:0~Max frequency
P426

Reaching frequency 2

Setting Range:0~Max frequency
FC100 Series set two groups of frequencies arrive,when output
frequency arrive the setting value of P425 and P426,corresponding
multi-function output terminal is ON. Frequency arrive width is of a
hysteresis loop,which is set by P430
P427

No. 1 timer

Setting Range:0~10.0S
P428

No. 2 timer

Setting Range:0~100S
FC100 series have two timers, when time of the timers reaches
value (set by P427 and P428), corresponding multi-function terminal
is ON.
Timer start is controlled by external multi-function input terminal.
Some simple program may be made by using these two timers.
Chapter 6 Description of parameter setting
77
Default value 100
Unit:0.1
Default value 5.0
Unit:0.1
Default value 0
Unit:0.1
Default value 0
Unit:1
setting
6
