3.4 Main Circuit Wiring

Single phase models input from R/L1, S/L2
LED display
Frequency
setting knob
Motor capacity
and input power
The signal selection
for AVI to input
DC0-+10V
or 4-20 mA

Control Terminal

Torque: 4Kgf-cm (3 in-lbf)
Wire: 22-24 AWG

Power Terminal

Torque: 5Kgf-cm (4.33 in-lbf)
Wire: 12-20 AWG
AC line input terminals
grounding
R/L1 S/L2 T/L3
U/T1 V/T2
Motor connections U/T1, V/T2, W/T3
Grounding
17
Chapter 3 Wire diagram and terminal explanation
UP/DOWN
Function
ENTER
DISP
Display key
Data
Confirmation key
RUN/STOP
RS485
communication
port
W/T3
