Chapter 6 Description of parameter setting
P014--P018. you can examine the frequency setting,actual output frequency, and
actual output current, output voltage,DC bus voltage of main circuit, According to
the above data,you can analyze the cause of fault and finds a solution quickly
which will help maintenance personnel in repair work
For FC100 Series, you can use parameter "F.00" to set the mian display data
It's also possible to monitor the data directly through the parameters "P001~P018"
You may monitor the data by pressing switching key as shown in the below table
Procedure
1
6
2
3
4
5
Press Key
Stop
Turn On Power
RUN
Press
RUN
Press
Once
Stop
Press
Once
Stop
Press
Once
Display
1,Inverter is in standby mode.
2,The keypad displays frequency
FWD
setting.
F50.0
FREE light is on, which means
that the keypad is displaying
frequency setting
Start inverter
1,Inverter is in running and RUN
FWD
light is on.
2,The image displays frequency
F50.0
setting.
Forward light is on; inverter is in
Forward state.
Switch display; stop switching
when actual output frequency is
FWD
displayed.
Inverter is in Forward running
H50.0
state.
① The actual output frequency is
50.0Hz.
Switch display; stop switching
FWD
when actual output current is
displayed.
A00.0
① The actual current output is 0A
FWD
Display running state
Frd
40
FC100 Series User Manaul
Explanation
