Chapter 6 Description of parameter setting

P209 Rated voltage motor

Please set rated voltage of motor according to voltage value on motor
nameplate.
P210 Rated motor current
Please set rated current of motor according to the current value on nameplate. If
the running current exceeds the value of rated current, inverter will trip to
protect the motor.
P211 No load current ratio of motor
The value of rated no load current of motor can affect slip
compensation. Rated no load current is the percentage of motor
current.
P212 Rated motor rotation speed
The value of parameter P112 is the rotation speed at 50Hz. It is related to
rotation speed display. Generally, it shall be set according to the value on
nameplate.
6
To display the actual rotation speed of motor, you can set parameter P212 at the
actual rotation speed at 50Hz.
P213 Number of motor poles
Set the number of pole pairs of motor by adjusting this parameter according to
the value on nameplate
P214 Rated motor slip
When inverter drives motor, slip will increase when load increase. Adjusting
P214 can compensation the slip and make motor speed close to the
synchronization speed.
P215

Rated motor frequency

Setting
Range:
0~400.0








































































Unit:0.1
P216

Resistance of stator

Setting
Range:
0~100.0








































































Unit:0.1
P217

Resistance of rotor

Setting
Range:
0~100.0








































































Unit:0.1
Factory Setting: 50HZ
Factory Setting: 2
Factory Setting: 4.5
56
