FC100 Series User Manaul
Chapter 6 Description of parameter setting

26. Winding function enable

When this signal is valid, winding function is enabled.
6
Introduction: Introduction:
1,Winding function is activated, and winding begins; 1,Winding function is activated, and winding begins;
2,Winding operation complete, inverter output according to the frequency 2,Winding operation complete, inverter output according to the frequency
that winding is completed. The multifunction terminal output the winding that winding is completed. The multifunction terminal output the winding
complete signal; complete signal;
3,Inverter stops, the winding complete signal reset. 3,Inverter stops, the winding complete signal reset.
P325

Output terminal - RA/RC

Default value 03
Setting Range:0~32 Unit:1
