Chapter 6 Description of parameter setting
P302 Input filter time
Value of input filter time decides the response speed of inverter to analogue
change. With the increase of value of P302, the inverter will get slower for
responding to analogue change.
P303

AVI minimum current input

Setting Range: 0~AVI Maximum
P304

AVI maximum current input

Setting Range: AVI minimum~20
P305

AVI input filter time

Setting Range:0~25.0
P303: AVI minimum current input
AVI minimum current input is related to frequency of lowest analogue input.
Inverter will deem current signal below value of P303 as invalid.
6
P304:AVI maximum current input
AVImaximum current input is related to frequency of highest analogue input.
For current command higher than value of P304, inverter will operate at the
value.

P305:AVI input filter time

AVI input filter time decides how fast inverter responds to analogue change.
With the increase of value of P305, inverter will respond more and more slowly
to analogue change. The output of inverter will be relatively stable.
Refer to explanations of P300 to P302 for relevant parameters.
If the external input is voltage signal, refer to P300-P302. If theexternal input is
current signal, refer to P303-P305.Current signal
For example,
corresponding frequency shall be within the range of 0-50Hz.
Parameters: P303=4 P304=20 P310= 0 P312=50, check as follows,
if the output signal
Factory Setting: 4.0
Factory Setting: 20.0
Factory Setting: 2.5
of upper computer
58
FC100 Series User Manaul
Unit:0.1
Unit:0.1
Unit:0.1
is 4-20mA, the
