FC100 Series User Manaul
Remark:0: terminal invalid 1: terminal invalid
13: acceleration / deceleration selection 1
14: acceleration / deceleration selection 2
4 kinds of acceleration / deceleration times can be selected by acceleration /
deceleration selection terminal l and 2.
Multi-function terminal
Acceleration/
deceleration
selection 1
0
1
0
1
15. Frequency increasing signal (Up signal)
When this terminal is valid, the frequency increases at a constant speed, until
operative frequency is highest.
16. Frequency decreasing signal (Down signal)
When this terminal is valid, the frequency decreases at a constant speed, until
operative frequency is lowest.
Attention: Inverter will not memorize the frequency setting changed by "UP" and
"DOWN" signal. When power is turned off and reset again, inverter still
memorizes the set value in P100.
Acceleration/
Acceleration / deceleration status
deceleration
and result
selection 2
Acceleration/ deceleration time 1
0
(P107, P108)
Acceleration/ dec eleration time 2
0
1
Acceleration/ deceleration time 4
1
65
Chapter 6 Description of parameter setting
(P401, P402)
Acceleration/ deceleration time 3
(P403, P404)
(P405, P406)
6
