J1 Switch Signal Summary

J1
HDD LED Connector
N.C.
Infrared Connector
N.C.
PWR
SLEEP
Pin Signal Description
1 +5V
2 HDD LED Signal
3 HDD LED Signal
4 +5V
5 No Connection
6 Infrared Transmit Signal
7 GND
8 Infrared Receive Signal
(low speed)
9 Infrared Receive Signal
(high speed)
10 +5V
11 No Connection
12 GND
13 Power Switch (for ATX
Power)
14 GND
15 Sleep Signal
Hardware Installation 21
