J1 Switch Signal Summary
J1
Speaker Connector
Reset Switch
N.C.
Power LED Connector
Keylock Connector
N.C.
Turbo LED Connector
Pin
Signal Description
1
Speaker Signal
2
No Connection
3
Ground
4
+5V
5
Reset Signal
6
Ground
7
No Connection
8
+5V
9
No Connection
10
Ground
11
Keylock Signal
12
GND
13
No Connection
14
Turbo LED Connector
15
Ground
Hardware Installation 19
