Jumper Settings

Factory Fixed Jumpers

The following jumpers are set by the factory.
Jumpers
JP8, JP6 Factory setting at open
JP2, JP7 Factory setting at Short

JP1, JP3: DIMM Connector Power Source

JP1 and JP3 can not be closed at the same time.
DIMM Type
3.3V EDO/Fast Page
DRAM (default)
5V EDO/Fast Page
DRAM

JP11: AT/ATX Power Select

Power Type
AT Power (12 pin)
(default)
ATX Power (20 pin)

FAN: Onboard FAN (12V) Connector

FAN pin
1
2
3
16
Factory settings
JP1 JP3
Open
Open
JP11
1 3
1 3
Function
GND
+12V
Sensor
