Thermal Grease Removal

Materials

Wipe, Isopropyl Alcohol

Procedure

Thermal Plate:
Refer to Figure 2Ð6 for diagram of each step.
1. Use wipe to remove large deposits of grease from the
backside of the heat sink.
2. Wipe with isopropyl alcohol until all visible traces of
grease are eliminated from the backside of the heat sink.
Note: Thermal plate may be slightly discolored.
3. Discard wipe.
PLGA Heat Slug
1. Use wipe to remove large deposits of grease from the
top side of the PLGA heat slug. Wipe until all visible
traces of grease are eliminated from the top side of the
heat slug.
Note: Be careful not to smear grease onto the PLGA body or the
processor card board.
2. Use wipe to clean deposits from the edges of the heat
slug.
Note: Be careful not to damage the chip caps on the PLGA when
wiping the edges (see Fig.3).
3. Re-wipe the top side of the heat slug.
