1.2 Specifications
General
• Disk drive housing: Space for one 2.5" HDD
• Dimensions: 342 mm(W) x 265 mm (H) x 61.5 mm (D)
• Weight: 2.7 kg
• Power supply: 50 Watts
Input voltage: 90~240V
Output voltage: +5V@4.5A, +12V@2A, -12V@0.3A
• Cooling fan dimensions: 60 x 60 x 15 mm (L x W x H)
• Front panel: IP65 protection
Standard PC Functions
• CPU: 486SX/DX/DX2-25/33/66/DX4-100/120, 5x86 series
• BIOS: AWARD 128KB flash memory
• Chipset: VIA VT82C496G
• 2nd level cache: on-board 128KB
• RAM: 2MB to 32 MB . One 72-pin SIMM socket (supports fast page mode
and EDO DRAM)
• Enhanced IDE HDD interface: Supports up to two IDE hard disks
• Floppy disk drive interface: Supports up to two floppy disk drives.
• Multi-mode parallel port: Supports SPP/ECP/EPP
• Serial ports: Three RS-232 ports (COM1*, COM3, and COM4), one RS-232/
422/485 port (COM2) (RS-485 is default)
• Battery: 3.6V @ 600 mA lithium battery
• Watchdog timer: Supports system reset or IRQ 15. Software enable/disable.
Time interval is 1.6 seconds.
*Note: The PPC-100 with the optionally installed touchscreen will share COM1.
@50/60 Hz
AC
