- Page 1 User Manual PPC-155T Pentium / Celeron M Processor- Based Panel PC with 15” Color TFT LCD Display Drivers & Manuals for Embedded Computing Platform...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight. -
Page 4: Technical Support And Assistance
Class I, Division 2, Groups A, B, C and D indoor hazards. Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. -
Page 5: Packing List
If the supplied unit is the basic version (i.e. without a CPU, HDD, or SDRAM), look for optional items in the accessory box. Note! If installing an Intel Æ processor, it is necessary to install a heat sink above the CPU. This will avoid heat damage to the CPU. PPC-155T User Manual... - Page 6 Visit the Advantech web site at www.advantech.com tocan find the latest infor- mation about the product. Contact the distributor, sales representative, or Advantech's customer service center for technical support and additional assistance. Please have the following information ready before calling: Product name and serial number Description of peripheral attachments Description of software (operating system, version, application software, etc.)
-
Page 7: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 8 Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC- 704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. PPC-155T User Manual viii...
- Page 9 Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. To avoid electrical shock, always disconnect the power from the PC chassis before working on it. Don't touch any components on the CPU card or other cards while the PC is on.
-
Page 11: Table Of Contents
Figure 4.10 Placing the heatsink and fan on the CPU .... 27 Figure 4.11 Fastening the CPU module to the motherboard .. 28 Installing the DDR SDRAM Memory Module ......29 Figure 4.12 Placing the memory module in the DIMM.... 29 PPC-155T User Manual... - Page 12 5.1.3 Connectors ..............35 Table 5.4: PPC-155T connectors table ........ 35 Chapter Driver Installation......38 Driver Installation ..............38 Updating Driver Searching on the Advantech Website.... 38 Appendix A Disassembly ......40 Disassembly Procedure ............40 Figure A.1 Unfastening the HDD side cover ......40 Figure A.2...
- Page 13 Chapter General Information This chapter gives background information on the PPC-155T Sections include: ! Specifications ! Dimensions...
-
Page 14: Chapter 1 General Information
General Information Introduction Advantech PPC-155T is an Intel Pentium-M processor based Panel PC with a bright 15” LCD display. The powerful Pentium-M/Celeron-M CPU and Intel 855GME chipset brings the most dynamic applications to life without sacrifices to any industrial reliabil- ity. -
Page 15: Table 1.1: Touchscreen Specifications
PCMCIA card/CardBus slots. Two sockets support both a 16-bit PCMCIA card and a 32-bit CardBus simultaneously. Hot insertion and removal. CF Interface: type II CF slot (IDE interface) for OS booting LAN: 2nd 10/100 Bases LAN or Giga LAN are optional PPC-155T User Manual... - Page 16 Temperature: 0 ~ 45° C (32 ~ 122° F) Relative humidity: 10 ~ 95% @ 40° C (non-condensing) Shock: 10 G peak acceleration (11 msec duration) Power MTBF: >130,000hrs 1.2.0.10 Certifications: EMC: CE, FCC, VCCI, BSMI, 3C BSMI approved Safety: CE, UL, CB. PPC-155T User Manual...
-
Page 17: Dimensions
Dimensions 379.5 103.5 396.5 Figure 1.1 Dimensions of PPC-155T PPC-155T User Manual... - Page 19 Chapter System Setup This chapter gives system setup information for the PPC-155T Sections include: ! A Quick Tour ! Installation Procedures ! Running the BIOS Setup ! Installing System Software...
-
Page 20: Chapter 2 System Setup
When viewed from the left side of the panel PC, the CD-ROM drive and PCMCIA expansion sockets are visible, as shown in Fig. 2-2: Hole for Panel mount HDD Cover PCMCIA CDR/DVD Speaker Figure 2.2 Left side view of the panel PC PPC-155T User Manual... -
Page 21: Figure 2.3 I/O Peripheral Connectors Panel
Both standard VESA standard 75 x 75 / 100 x 100 mm mounting sizes are supported, so that customers may install different accessories for various applications. VESA mou nt Figure 2.4 Rear view of the panel PC PPC-155T User Manual... -
Page 22: Preparing For First-Time Use
CMOS RAM and compares them to the equip- ment check conducted during the power on self-test (POST). If a problem occurs, an error message will be displayed on screen, and the computer prompts the user to run the setup program. PPC-155T User Manual... -
Page 23: Installing System Software
Note! The drivers and utilities used for the PPC-155T panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities. - Page 25 Chapter Using the Panel PC This chapter explains onboard devices and peripherial I/O ports available on the PPC-155T Sections include: ! CD-ROM Drive ! PCMCIA ! PS/2 Mouse and Keyboard ! PCI Bus Expansion ! Serial COM Ports ! VGA Port ! USB Ports ! Audio Interface ! Ethernet...
-
Page 26: Chapter 3 Using The Panel Pc
To insert a CD-ROM disc, press the eject button on the CD-ROM drive. To eject a CD-ROM disc, first ensure that the drive activity light is not active. Then press the eject button on the drive. Figure 3.1 Inserting and ejecting a CD-ROM PPC-155T User Manual... -
Page 27: Pcmcia
To install a full-size desktop PS/2 keyboard and mouse with the panel PC, follow these instructions: Be sure the panel PC is turned off. Attach the keyboard to the purple colored 5-pin PS/2 port. Attach the PS/2 mouse to the green colored port. Turn on the panel PC. PPC-155T User Manual... -
Page 28: Pci Bus Expansion
Remove the metal plate by unscrewing the single attaching screw. Insert the PCI bus card into the PCI slot of the riser card. (See Fig. 3-3) Run the setup program within the OS to configure the system. Figure 3.3 PCI bus expansion PPC-155T User Manual... -
Page 29: Serial Com Ports
An external USB device may be connected to the system through the 4-pin USB ports located on the rear side of the system unit. Connect the external device to the system. (See Fig. 3-4.) The USB ports support hot plug-in connection. Install the device driver before using the device. PPC-155T User Manual... -
Page 30: Audio Interface
Details about the light sensor are available on the Driver CD, inside the “light sensor” folder. The Advantech “Smart Backlight Utility” is aimed to help the user adjust the backlighting of the panel. Users can also configure the backlight of the panel from desktop utility;... -
Page 31: Touchscreen (Optional)
There are 3 kinds of touchscreens that support the PPC-155T: resis- tive, capacitive and SAW type. It is necessary to install the touchscreen driver before it will function. The touch- screen drivers for various operating systems are stored on the CD-ROM disc inside the accessory box. PPC-155T User Manual... - Page 33 Chapter Hardware Installation This chapter gives instructions for installing hardware devices on the PPC-155T Sections include: ! Jumpers and Connectors ! Disassembling the Panel PC ! Installing the Central Processing Unit (CPU) ! Installing the DDR SDRAM Memory Module...
-
Page 34: Chapter 4 Hardware Installation
All procedures are illustrated in Fig. 4-1, 4-2, 4-3 and 4-4. Unscrew the side cover on the plastic HDD cover to expose the HDD module. The Type II CF slot lies underneath the HDD module. Figure 4.1 Unfastening the HDD side cover PPC-155T User Manual... -
Page 35: Figure 4.2 Unfastening The Rear Cover
Unfasten the screws securing the rear plastic cover and remove it. Figure 4.2 Unfastening the rear cover Before removing the rear cover, disconnect the system fan connector. Figure 4.3 Disconnecting the fan connector PPC-155T User Manual... -
Page 36: Figure 4.4 The Ppc Without The Rear Cover
(See Fig. 4-5.) Fix the two screws on the metal plate of two side of HDD. Connect IDE cable from main board. Place the HDD on the metal plate, and tighten the four screws from the bottom of the metal plate. Figure 4.5 Fastening the HDD metal frame to the HDD PPC-155T User Manual... -
Page 37: Figure 4.6 Plugging In The Eide Cable
Plug the EIDE cable connector into the HDD. Figure 4.6 Plugging in the EIDE cable Align the metal frame on the HDD to the mounting points and fasten the four screws. Figure 4.7 Aligning the HDD frame PPC-155T User Manual... -
Page 38: Installing The Central Processing Unit (Cpu)
Only experienced electronics personnel should open the panel Follow these instructions to install a CPU: Place the CPU carefully into the socket, taking care to align it properly. Figure 4.8 Placing the CPU in the socket PPC-155T User Manual... -
Page 39: Figure 4.9 Tightening The Screws On The Cpu
Fasten the screw on the CPU socket mounting plate. Figure 4.9 Tightening the screws on the CPU Place the heatsink and fan on top of the CPU, and fasten them with the reten- tion bracket. Figure 4.10 Placing the heatsink and fan on the CPU PPC-155T User Manual... -
Page 40: Figure 4.11 Fastening The Cpu Module To The Motherboard
Fasten the four screws onto the CPU cooler module. Figure 4.11 Fastening the CPU module to the motherboard PPC-155T User Manual... -
Page 41: Installing The Ddr Sdram Memory Module
It is possible to install from 256 MB to 2 GB of DDR SDRAM memory. The panel PC system provides two 184-pin DIMM (Dual Inline Memory Module) sockets and sup- ports 2.5V DDR SDRAM. Figure 4.12 Placing the memory module in the DIMM PPC-155T User Manual... - Page 43 Chapter Jumpers and Connectors This chapter gives information on setting jumpers and using the connectors on the PPC-155T motherboard Sections include: ! Setting Jumpers ! Jumper and Connector Locations ! Connectors...
-
Page 44: Chapter 5 Jumpers & Connectors
It also has LED indicator lamps that display the system operation status. The table below lists the function of each jumper and LED. The motherboard of the PPC-155T has a number of jumpers that allow you to config- ure your system to suit your applications. PPC-155T User Manual... -
Page 45: Table 5.1: Pci Slot Voltage Setting (Jp2)
LVDS voltage setting (JP5) The panel PC supports 5V and 3.3V LVDS voltages. The default voltage is 3.3V (closed pins 1-2). 5V may be selected by closing jumpers 2-3. Table 5.3: LVDS voltage setting (JP5) 3.3V (default) PPC-155T User Manual... - Page 46 5.1.2.4 Jumper and Connector Locations CN12 CN16 CN30 CN34 CN37 CN13 CN19 Figure 5.1 Jumpers and connectors on the PPC-155T motherboard PPC-155T User Manual...
-
Page 47: Table 5.4: Ppc-155T Connectors Table
CN13 CPU fan CN33 1394 port CN14 CN34 System FAN CN15 CN35 COM*2 CN16 internal USB pin header CN36 2nd LAN CN17 internal Speakers CN37 Power Switch CN18 CN38 Light sensor CN19 CN39 LED*3 CN20 USB*2 CN40 PPC-155T User Manual... - Page 49 Chapter Driver Installation This chapter gives information on installing drivers for the PPC-155T Sections include: ! Driver Installation ! Updating Drivers...
-
Page 50: Chapter 6 Driver Installation
2. <Enter> means pressing the "Enter" key on the keyboard. Updating Driver Searching on the Advantech Website For further information about installing drivers on the PPC-155T, and to access driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Advantech websites: www.advantech.com www.advantech.com.tw PPC-155T User Manual... - Page 51 Appendix Disassembly This chapter details a complete procedure for dissasembling the Panel PC...
-
Page 52: A.1 Disassembly Procedure
Disassembly Procedure To completely disassemble the panel PC, follow the step-by-step procedures below. Users should be aware that Advantech Co., Ltd. takes no responsibility whatsoever for any problems or damage caused by disassembly of the panel PC by the user. -
Page 53: Figure A.2 Unfastening The Rear Cover
Unfasten the rear cover and remove it. Figure A.2 Unfastening the rear cover Before removing the rear cover, disconnect the system fan connector. Figure A.3 Disconnecting the fan connector PPC-155T User Manual... -
Page 54: Figure A.4 The Ppc Without The Rear Cover
The PPC without the rear cover. Figure A.4 The PPC without the rear cover Remove the PCI riser card. Figure A.5 Removing the PCI riser card PPC-155T User Manual... -
Page 55: Figure A.6 Unfastening The Middle Plate
Unfasten the middle plate. Figure A.6 Unfastening the middle plate Remove the middle plate. Figure A.7 Removing the middle plate PPC-155T User Manual... -
Page 56: Figure A.8 Unfastening The Hdd Module
Unfasten the side screws on the HDD module and remove the left side plate. Figure A.8 Unfastening the HDD module Remove the right side plate and lift out the HDD. Figure A.9 Removing the HDD PPC-155T User Manual... -
Page 57: Figure A.10 Disconnecting The Hdd Cable
Disconnect the HDD cable from the PPC-155T motherboard. Figure A.10 Disconnecting the HDD cable Loosen the screws on the bracket holding the HDD module. Figure A.11 Loosening the screws on the HDD bracket PPC-155T User Manual... -
Page 58: Figure A.12 Loosening The Screws On The Cd-Rom Module
Loosen the screws on the CD-ROM module. Figure A.12 Loosening the screws on the CD-ROM module Carefully push out the fixed brace holding the CD-ROM. Figure A.13 Pushing out the brace holding the CD-ROM PPC-155T User Manual... -
Page 59: Figure A.14 Removing The Fixed Brace
Remove the fixed brace. Figure A.14 Removing the fixed brace Unfasten the CD-ROM / PCMCIA slot cover. Figure A.15 Unfastening the CD-ROM / PCMCIA slot cover PPC-155T User Manual... -
Page 60: Figure A.16 Removing The Cd-Rom / Pcmcia Slot Cover
Remove the CD-ROM / PCMCIA slot cover. Figure A.16 Removing the CD-ROM / PCMCIA slot cover. Remove the CD-ROM module. Figure A.17 Removing the CD-ROM module PPC-155T User Manual... -
Page 61: Figure A.18 Disconnecting The Cd-Rom Connector
Disconnect the CD-ROM connector. Figure A.18 Disconnecting the CD-ROM connector Unfasten the four screws on the CPU module and remove it. Figure A.19 Removing the CPU module PPC-155T User Manual... -
Page 62: Figure A.20 Unfastening The Cpu Socket
Unsfasten the CPU socket. Figure A.20 Unfastening the CPU socket Unfasten the screw on the CPU socket mounting plate and remove the CPU. Figure A.21 Removing the CPU PPC-155T User Manual... -
Page 63: Figure A.22 Removing The Sdram Module
Remove the SDRAM module. Figure A.22 Removing the SDRAM module PPC-155T User Manual... - Page 65 Appendix PCI Card Size Limits This chapter details the size limits for PCI cards that may be installed on the Panel PC motherboard...
-
Page 66: Appendix B Pci Card Size Limits
Appendix B PCI Card Size Limits PCI Cards must be sized within the following dimensional limits: 100.4 106.4 Figure B.1 PCI Card Dimensional Limits PPC-155T User Manual... - Page 68 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2006...
