Advantech PPC-123T
Pentium III Processor-Based Panel PC
A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
• C r i t i c a l a n d e x p e d i t e d s e r v i c e s
• I n s t o c k / R e a d y - t o - s h i p
Artisan Scientific Corporation dba Artisan Technology Group is not an affiliate, representative, or authorized distributor for any manufacturer listed herein.
$
2895
.00
In Stock
Qty Available: 1
Used and in Excellent Condition
Open Web Page
https://www.artisantg.com/61070-1
• We b u y y o u r e x c e s s , u n d e r u t i l i z e d , a n d i d l e e q u i p me n t
• F u l l - s e r v i c e , i n d e p e n d e n t r e p a i r c e n t e r

Advertisement

loading
Need help?

Need help?

Do you have a question about the PPC-123T and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech PPC-123T

  • Page 1 Advantech PPC-123T Pentium III Processor-Based Panel PC 2895 In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/61070-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 PPC-123 Pentium® III processor-based panel PC with 12.1" LCD flat panel display User’s Manual...
  • Page 3 Copyright notice This document is copyrighted 2001, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to alter the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
  • Page 4 Packing List Before installing your panel PC, ensure that the following materials have been received: • PPC-123 series panel PC • User's manual • Accessories for PPC-123 - Y-shaped adapter for PS/2 mouse and keyboard - Power cord (1.8 m) - USA type (other types are available on request) - Floppy disk with CD-ROM drive driver - "Drivers and Utilities"...
  • Page 5 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.
  • Page 6 Additional Information and Assistance 1. Visit the Advantech websites at www.advantech.com or www.advantech.com.tw where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 7 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 8 60° C (140° F), weil diesen Temperaturen das Gerät zerstören könten. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70 dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 9 Contents Chapter 1 General Information Introduction ............. 2 How to Use This Manual .......... 4 Specifications ............6 General ..................6 Standard PC functions ............. 6 Flat panel interface ..............7 Audio function ................7 PCI bus Ethernet interface ............8 PCMCIA interface ..............
  • Page 10 PS/2 Mouse and Keyboard ........31 PCI/ISA Bus Expansion ......... 31 Parallel Port ............33 Serial COM Ports..........33 VGA Port .............. 34 3.10 Game Port ............34 3.11 USB Ports ............34 3.12 Audio Interface ............35 3.13 Ethernet ..............35 3.14 Adjusting the LCD Contrast and Brightness ...
  • Page 11 Internal -12 V source selection setting (JP1) ..56 VGA Interface ............57 5.6.1 LCD panel power setting ..........57 5.6.2 Panel type select (SW3) ..........57 Watchdog Timer Configuration ......58 5.7.1 Watchdog activity selection (JP7) ......... 58 Chapter 6 PCI Bus Ethernet Interface Introduction ............
  • Page 12 Standard CMOS Setup ......... 85 9.3.1 Hard Disk Configurations ..........86 BIOS Features Setup ..........87 Chipset Features Setup ........91 Power Management Setup ........93 PNP/PCI Configuration Setup ....... 96 Load BIOS Defaults ..........97 Load Setup Defaults ..........97 9.10 Integrated Peripherals ...........
  • Page 13 Appendix B Programming the Watchdog Timer Programming the Watchdog Timer ...... 128 Appendix C Full Disassembly Procedures Full Disassembly Procedures ......132 Appendix D Pin Assignments AT Power Connector (J1) ........140 TV Output Connector (J2) (*Reserved) ....140 Inverter Power Connector (J4) ......141 Internal Speaker Connector (J6) ......
  • Page 14 Figures Figure 1-1: The panel PC in perspective ..........3 Figure 1-2: How to read the PPC-123 manual ........5 Figure 1-3: Dimensions of the PPC-123 ..........10 Figure 2-1: Front view of the panel PC ..........12 Figure 2-2: Left side view of the panel PC ........... 13 Figure 2-3: Rear view of the panel PC ..........
  • Page 15 Figure C-1: Disassembly steps 1 - 4 ..........133 Figure C-2: Disassembly steps 5 - 6 ..........135 Figure C-3: Disassembly steps 7 - 11 ..........137 Figure E-1: Cutout dimensions of the PPC-123 ........ 158 Figure E-2: Panel mounting .............. 159 Figure E-3: Desktop stand mounting ..........
  • Page 16 Tables Table 5-1: Jumpers and their functions ..........49 Table 5-2: Panel PC connectors ............51 Table 5-3: Clear CMOS / External RTC (JP8) ........53 Table 5-4: COM2 RS-232/422/485 setting (JP3, JP4) ......54 Table 5-5: COM2 RS-232/422/485 setting (JP5) ........54 Table 5-6: Serial port default settings ..........
  • Page 18 General Information This chapter gives background information on the PPC-123 panel PC. • Introduction • How to Use This Manual • Specifications • Dimensions...
  • Page 19 1.1 Introduction ® The PPC-123 panel PC is a multimedia Pentium III processor-based computer that is designed to serve as a human machine interface (HMI) and as a desktop computer. It is a PC-based system with 12.1" color TFT LCD display, on-board PCI Ethernet controller, multi-COM port interfaces and a 16-bit stereo audio controller.
  • Page 20 CRT Monitor Touchscreen Network modem Speakers Printer Keyboard Joystick Mouse Figure 1-1: The panel PC in perspective Chapter 1 General Information...
  • Page 21 1.2 How to Use This Manual This manual contains all the information you need to set up and use the panel PC. In addition to this manual, you may also want to consult the manuals for your operating system, software applica- tions and peripherals.
  • Page 22 Appendix D includes all pin assignments on the connectors. Appendix E helps users install the panel PC, which is mountable in a variety of ways. If you are a commercial user and the panel PC unit you bought is a complete set with CPU, hard disk drive, SDRAM, CD-ROM drive, floppy disk drive and PCMCIA expansion slots included, you may only need to read Chapters 1 through 3 regarding hardware...
  • Page 23 1.3 Specifications General • Dimensions (W x H x D): 375 x 285 x 93.3 mm (14.7" x 11.2" x 3.7") • Weight: 5.2 kg (11.5 lb) • Power supply: AC model: 80 watts Input voltage: 100~250 V , 3 A max. @ 50 ~ 60 Hz Output voltage: +5 V @ 12 A, +12 V @ 1 A DC model: 60 watts Input voltage: 24 V...
  • Page 24 •Floppy disk drive: Supports up to two FDDs (720 KB / 1.44 MB). One built-in FDD included inside FDD housing. • Parallel port: One parallel port, supports SPP/EPP/ECP parallel mode. BIOS configurable to LPT1, LPT2, LPT3 or disabled • Serial ports: Four serial ports with three RS-232 ports (COM1, 3, and 4), one RS-232/422/485 port (COM2).
  • Page 25 • Audio interface: Microphone-in, Line-in, Line-out and Game ports (MPU-401) PCI bus Ethernet interface • Chipset: Realtek RTL 8139 PCI local bus Ethernet controller • Ethernet interface: Full compliance with IEEE 802.3u 100Base-T and 10Base-T specifications. Includes software drivers and boot •...
  • Page 26 Note: The panel PC with the optionally installed touch- screen will share COM4. Once the touchscreen is installed, COM4 cannot be used for other purpos- Optional modules ® • CPU: Intel Celeron™ or Pentium® III up to 850 MHz • Memory: 32/64/128/256 MB SDRAM •...
  • Page 27 1.4 Dimensions Unit: mm Figure 1-3: Dimensions of the PPC-123 PPC-123 User's Manual...
  • Page 28 System Setup • A Quick Tour of the Panel PC • Preparing for First-time Usage • Running the Setup Program • Installing the System Software • Installing the Drivers...
  • Page 29 2.1 A Quick Tour of the Panel PC Before you start to set up the panel PC, take a moment to become familiar with the locations and purposes of the controls, drives, connectors and ports, which are illustrated in the figures below. When you place the panel PC upright on the desktop, its front panel appears as shown in Figure 2-1.
  • Page 30 When you look at the left side of the panel PC, you will see the floppy disk drive, CD-ROM drive and PCMCIA expansion sockets, as shown in Fig. 2-2. Compact CD-ROM drive FDD eject button CD-ROM drive activity light FDD slot CD-ROM eject button PCMCIA socket FDD activity light...
  • Page 31 PCI/ISA expansion slot cover PS/2 mouse and keyboard connector USB ports Ethernet jack Parallel port Brightness adjust knob Serial ports Contrast adjust knob Line-out jack VGA port Line-in jack Game port Microphone-in jack Figure 2-3: Rear view of the panel PC Figure 2-4 shows the I/O section and power switch of the panel PC.
  • Page 32 2.2 Preparing For First-time Use Before you start to set up the panel PC system, you should have at least the following items ready: • Power cord (in the accessory box) • Y-shaped connector (in the accessory box) • keyboard •...
  • Page 33 2.3.2 Installing the DC power insulator with hood The panel PC can also be powered by DC electrical outlet (24 V or 12 , which depends on the power type). Follow the procedure in order to install the DC power insulator with hood then make sure to connect the insulator with the system.
  • Page 34 frame ground ( G ), and pin 3 should be plugged into the negative DC power input ( - ). STEP 3 : Mount the front part of the male insulator onto the bottom tray. STEP 4: Use the metal plate and the two screws to secure the cables to the bottom tray.
  • Page 35 STEP 5 Attach the upper cap to the bottom tray and secure it with the screws. STEP 6 Now that you have completed the assembly of the male insulator, plug it into the female insulator. PPC-123 User's Manual...
  • Page 36 2.3.3 Connecting the keyboard and mouse 1. Connect the Y-shaped adapter to the PS/2 mouse and keyboard port on the I/O section of the panel PC. (See Fig. 2-6.) 2. Connect the PS/2 mouse and keyboard to the Y-shaped adapter. (See Fig.
  • Page 37 2.4 Running the BIOS Setup Program Your panel PC is likely to have been properly set up and configured by your dealer prior to delivery. You may still find it necessary to use the panel PC's BIOS (Basic Input-Output System) setup program to change system configuration information, such as the current date and time or your type of hard drive.
  • Page 38 2.5 Installing System Software Recent releases of operating systems from major vendors include setup programs which load automatically and guide you through hard disk preparation and operating system installation. The guidelines below will help you determine the steps necessary to install your operating system on the panel PC hard drive.
  • Page 39 2.6 Installing the Drivers After installing your system software, you will be able to set up the Ethernet, SVGA, audio, PCMCIA and touchscreen functions. All the drivers except the CD-ROM drive driver are stored in a CD-ROM disc entitled "Drivers and Utilities." The CD-ROM drive driver is stored in a floppy disk.
  • Page 40 Note: The drivers and utilities used for the PPC-123 panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utlities. Chapter 2 System Setup...
  • Page 41 PPC-123 User's Manual...
  • Page 42 Using the Panel PC • Floppy Drive • CD-ROM Drive • PCMCIA Sockets • PS/2 Mouse and Keyboard • Audio Interface • PCI/ISA Bus Expansion • Parallel Port • Serial COM Ports • VGA Port • Game Port • USB Ports •...
  • Page 43 3.1 Introduction This chapter describes basic features and procedures for using the panel PC. Topics covered include the floppy drive, CD-ROM drive, I/O ports, touchscreen, and so on. 3.2 Floppy Drive To insert a diskette, hold it with your left hand, between your thumb and your other fingers, and push it toward the drive.
  • Page 44 3.3 CD-ROM Drive To insert a CD-ROM disc, press the eject button of the CD-ROM drive. The yellow activity light will flash and the front panel will come out a short distance. Using your fingertips, hold the top and bottom of the front panel and pull it outward to the very end.
  • Page 45 3.4 PCMCIA PCMCIA cards are inserted and ejected in much the same way as diskettes. To insert a PCMCIA card, align the card with the socket and slide the card into the socket until it locks into place. Note that some PCMCIA memory cards must be prepared by your operating system before you can use them for data storage.
  • Page 46 PS/2 Network mouse Printer keyboard Figure 3-4: Using the I/O interface (upper level ports excluding COM ports) Chapter 3 Using the Panel PC...
  • Page 47 Serial CD-ROM player monitor mouse Headphones Microphone Joystick Figure 3-5: Using the I/O interface (lower level ports and COM ports) PPC-123 User's Manual...
  • Page 48 3.5 PS/2 Mouse and Keyboard If you wish to use a full-size desktop keyboard and PS/2 mouse with your panel PC, follow these instructions: 1. Be sure the panel PC is turned off. 2. Connect the Y-shaped adapter to the PS/2 mouse and keyboard port on the rear bottom side of the rear cover.
  • Page 49 PCI/ISA expansion slot cover PCI/ISA bus card Metal plate Figure 3-6: PCI/ISA bus expansion PPC-123 User's Manual...
  • Page 50 3.7 Parallel Port The panel PC supports the latest EPP and ECP parallel port protocols for improved performance and versatility with compatible printers or other devices. To connect the panel PC to a printer or other devices: 1. Be sure both the panel PC and the printer/devices are turned off. 2.
  • Page 51 3.9 VGA Port An external VGA-compatible device may be connected to the system through the 15-pin external port located on the rear of the system unit. The panel PC simultaneously supports an external CRT monitor in addition to its own LCD display. 1.
  • Page 52 3.12 Audio Interface The audio interface includes three jacks: microphone in, line out and line in. (See Fig. 3-5.) Their functions are: Microphone in: Use an external microphone to record voice and sound. Line out: Output audio to external devices such as speakers or earphones.
  • Page 53 3.15 Infrared Module This sensor on the front panel supports the optional wireless transmit- ting and receiving of infra-red data. (See Fig. 2-1.) You must configure the setting through the BIOS setup (chipset features) to select whether UART2 is directed for use with COM2 or IrDA. 1.
  • Page 54 Hardware Installation and Upgrading • Overview of Hardware Installation and Upgrading • Disassembling the Panel PC • Installing the 2.5" Hard Disk Drive (HDD) • Installing the Central Processing Unit (CPU) • Installing the SDRAM Memory Module • Installing the Floppy Disk Drive (FDD) and CD-ROM Drive...
  • Page 55 4.1 Overview of Hardware Installation and Upgrading The panel PC consists of a PC-based computer that is housed in a plastic rear panel and a metal shielding case. Your HDD, SDRAM, power supply, CPU, and so on are all readily accessible by removing the rear panel and shielding case.
  • Page 56 Plastic rear cover CPU fan and cover PCI/ISA expansion PCB Side panel Figure 4-1: Disassembling the plastic rear cover of the panel PC Chapter 4 Hardware Installation and Upgrading...
  • Page 57 4.3 Installing the 2.5" Hard Disk Drive (HDD) You can attach one enhanced Integrated Device Electronics (IDE) hard disk drive to the panel PC's internal controller which uses a PCI local-bus interface. The advanced IDE controller supports faster data transfer and allows the IDE hard drive to exceed 528 MB. The follow- ing are instructions for installation: 1.
  • Page 58 4.4 Installing the Central Processing Unit (CPU) The panel PC's central processing unit (CPU) can be upgraded to improve system performance. The panel PC provides one 370-pin ZIF (Zero Insertion Force) socket (Socket 370). The CPU must come with an attached heat sink and CPU fan to prevent overheating. Warning! The CPU may be damaged if operated without a heat sink and a fan.
  • Page 59 8. Insert the CPU with the correct orientation. The notched corner of the CPU (with the white dot) should point towards the end of the lever. The end of the lever is the blank area where one hole is missing from the corner of the square array of pin holes. An arrowhead printed on the motherboard points to the end of the lever.
  • Page 60 CPU fan CPU cover Heat sink clip Heat sink Lever Socket 370 Figure 4-3: Installing the CPU Chapter 4 Hardware Installation and Upgrading...
  • Page 61 4.5 Installing the SDRAM Memory Module You can install from 32 to 256 MB of SDRAM memory. The panel PC system provides one 168-pin DIMM (Dual Inline Memory Module) socket and supports 3.3 V SDRAM with a minimum speed of 12 ns. Note: The module can fit into the socket only one way.
  • Page 62 4.6 Installing the Floppy Disk Drive (FDD) and Slim CD-ROM Drive Installation of a floppy disk drive and slim CD-ROM drive is similar to that for a hard disk drive. The metal plate for holding the FDD and the CD-ROM support bracket are on the left side of the shielding case. The 26-pin and 40-pin yellow FPC cables are for connecting the FDD and CD-ROM respectively.
  • Page 63 9. Connect the FDD cable (26-pin to 26-pin) and CD-ROM cable (40-pin to 40-pin). The other end of the FDD cable is connected to connector CN10 on the PC board. The other end of the CD-ROM cable is connected to connector CN18 on the PC board. 10.
  • Page 64 Jumper Settings and Con- nectors This chapter tells how to set up the panel PC hardware, including instructions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedures.
  • Page 65 5.1 Jumpers and Connectors 5.1.1 Setting jumpers You can configure your panel PC to match the needs of your applica- tion by setting jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 66 5.1.2 Jumpers and switch The motherboard of the panel PC has a number of jumpers that allow you to configure your system to suit your applications. The table below lists the function of each of the board’s jumpers. Table 5-1: Jumpers and their functions Label Function Internal -12 V source selection setting...
  • Page 67 5.1.3 Locating jumpers and switch JP7: Watchdog timer action JP2: Wake on LAN JP8: CMOS clear (Reserved) for external RTC JP1: Internal -12 V source selection setting SW3: Panel type setting JP6: COM3 / COM4 JP3: COM2 Pin 9 output type RS-232/422/485 setting setting...
  • Page 68 5.1.4 Connectors Onboard connectors link the panel PC to external devices such as hard disk drives or floppy drives. The table below lists the function of each of the board’s connectors. Table 5-2: Panel PC connectors Label Function AT power connector Inverter power connector Internal speaker connector (Reserved) Front panel control connector (Reserved)
  • Page 69 5.1.5 Locating connectors FAN2: System fan J8: Front panel power connector J4: Inverter power control connector connector (Reserved) J1: AT power connector J6: Internal speaker connector (Reserved) SLOT1: PCI/ISA expansion connector FAN1: CPU fan power connector CN16: EIDE hard disk drive CN10: Floppy connector drive connector...
  • Page 70 5.2 CPU Installation You can install an Intel Celeron™ or Pentium® III CPU without setting any frequency ratio or voltage. 5.3 CMOS Clear for External RTC (JP8) Warning: To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS”. Set the jumper back to “Normal operation”...
  • Page 71 5.4 COM-port Interface The panel PC provides four serial ports (COM1, 3, 4: RS-232; COM2: RS-232/422/485) in one COM port connector. 5.4.1 COM2 RS-232/422/485 setting (JP3, JP4, JP5) COM2 can be configured to operate in RS-232, RS-422, or RS-485 mode. This is done via JP3, JP4 and JP5. Table 5-4: COM2 RS-232/422/485 setting (JP3, JP4) *RS-232 RS-422/485...
  • Page 72 COM1 and COM2 are one set. You can exchange the address range and interrupt IRQ of COM1 for the address range and interrupt IRQ of COM2. After exchanging, COM1's address range is 2F8 ~ 2FF and its request IRQ is IRQ3: and COM2's address range is 3F8 ~ 3FF and its interrupt IRQ is IRQ4.
  • Page 73 5.4.3 COM3 / COM4 pin 9 output type setting (JP6) Table 5-8: COM3/COM4 pin 9 output type setting (JP6) *Normal operation +5 V output +12 V output * default setting Note: Pins 1, 3 and 5 are for COM3. Pins 2, 4 and 6 are for COM4. 5.5 Internal -12 V source selection setting (JP1) The panel PC provides an internal -12 V source in an extension slot...
  • Page 74 5.6 VGA Interface The panel PC's AGP VGA interface can drive conventional CRT displays. It is also capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD and active LCD displays. The board has two connectors to support these displays simultaneously: one for standard CRT VGA monitors, and one for flat panel displays.
  • Page 75 5.7 Watchdog Timer Configuration An onboard watchdog timer reduces the chance of disruptions which EMP (electromagnetic pulse) interference can cause. This is an invaluable protective device for standalone or unmanned applications. Setup involves one jumper and running the control software. (Refer to Appendix B.) 5.7.1 Watchdog activity selection (JP7) When the watchdog timer activates (i.e.
  • Page 76 PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet Driver - for Windows 95 - for Windows 98 - for Windows NT - for Wiindows 2000/ME • Further Information...
  • Page 77 6.1 Introduction The PPC-123 is equipped with a high performance 32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/ CD standards. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible. The medium type can be configured via the RSET8139.exe program included on the utility disk.
  • Page 78 6.2.1 Installation for Windows 95 a. Select "Start", "Settings", "Control Panel", "System". b. Click the "Device Manager" and "Other Devices" items. c. Remove the "PCI Ethernet Controller" item. a. Select "Start", "Settings", "Control Panel", and "Network" icons. Click the "Add" button. Select "Adapter", and then click the "Add"...
  • Page 79 Type the path "D:\ PPC123~7\LAN\ W95OSR2" Click the "OK" button. a. Choose the highlighted "Realtek RTL8139(A/B/C/ 8130)PCI Fast Ethernet". Press the "OK" button. Press the "Add..." button to select suitable services or protocol. Press the "OK" button to finish network configuration.
  • Page 80 6.2.2 Installation for Windows 98 a. Select "Start", "Settings", "Control Panel", "System" b. Click "Device Manager" and highlight "PCI Ethernet Controller" c. Select "Properties" a. Choose "Driver" folder Click "Update Driver" Follow the instructions b. Click "Next" Chapter 6 PCI Bus Ethernet Interface...
  • Page 81 a. Click "Next" a. Select "Network Adaptors" b. Click "Next" Choose "Have Disk" Type the path "D:\ 123&153\LAN\WIN98" b. Click "OK" PPC-123 User's Manual...
  • Page 82 a. Click "OK" a. Click "Next" Click "Finish" Select "Yes" to reboot system Chapter 6 PCI Bus Ethernet Interface...
  • Page 83 6.2.3 Installation for Windows NT a. Select "Start", "Settings", "Control Panel", and then double click the "Network" icon. b. Choose the "Adapters" label. c. Click the "Add" button. a. Press "Have Disk...". Type the path "D:\ PPC123&153\LAN\ WINNT. Press the "OK" button. PPC-123 User's Manual...
  • Page 84 Choose the highlighted "RTL8139(A/B/C/ 8130)PCI Fast Ethernet Adapter. Click the "OK" button. Choose a suitable RTL8139 Duplex mode for your application. Finish the network configuration and then click the "OK" button. 6.2.4 Installation for Windows 2000/ME After finishing the Windows 2000/ME installation, the system will automatically detect the Ethernet hardware and install the Ethernet driver from the drivers database from Windows 2000 or Windows ME when the system reboots.
  • Page 85 6.3 Further Information Realtek website: www.realtek.com.tw Advantech websites: www.advantech.com www.advantech.com.tw PPC-123 User's Manual...
  • Page 86 AGP SVGA Setup • Introduction • Installation of SVGA Driver - for Windows 95/98 - for Windows NT - for Windows 2000 - for Windows ME • Further Information...
  • Page 87 7.1 Introduction The PPC-123 has an onboard AGP flat panel/VGA interface. The specifications and features are described as follows: 7.1.1 Chipset The PPC-123 uses a Lynx3DM8 SMI721 chipset from Silicon Motion Inc. for its AGP/SVGA controller. It supports many popular LCD, EL, and gas plasma flat panel displays and conventional analog CRT monitors.
  • Page 88 7.2 Installation of SVGA Driver Complete the following steps to install the SVGA driver. Follow the procedures in the flow chart that apply to the operating system that you you are using within your PPC-123. Important: The following windows illustrations are examples only.
  • Page 89 7.2.1 Installation for Windows 95/98 a. Select "Start", "Run" Type the path "D:\ 123&153\VGA(3DM)\ Win9x\Setup.exe Click "OK" a. Click "Next" Click "Finish" to reboot the system PPC-123 User's Manual...
  • Page 90 7.2.2 Installation for Windows NT a. Select "Start", "Run" Type the path "D:\ 123&153\ VGA(3DM)\WinNT\ Setup.exe Click "OK" a. Click "Next" Click "Finish" to reboot the system Note: Service Pack X (X=3, 4, 5, 6...) must be installed first before you install the Windows NT VGA driver. Chapter 7 PCI SVGA Setup...
  • Page 91 7.2.3 Installation for Windows 2000 a. Select "Start", "Run" Type the path "D:\ 123&153\VGA(3DM)\ Win2000\Setup.exe Click "OK" a. Click "Next" Click "Finish" to reboot the system PPC-123 User's Manual...
  • Page 92 7.2.4 Installation for Windows ME a. Select "Start", "Run" Type the path "D:\ 123&153\VGA(3DM)\ WinME\Setup.exe Click "OK" a. Click "Next" Click "Finish" to reboot the system Chapter 7 PCI SVGA Setup...
  • Page 93 7.3 Further Information For further information about the AGP SVGA installation in your PPC-123, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Silicon Motion website: www.siliconmotion.com Advantech websites: www.advantech.com www.advantech.com.tw PPC-123 User's Manual...
  • Page 94 Audio • Introduction • Installation of Audio Driver - for Windows 95/98 - for Windows NT - for Windows 2000/ME...
  • Page 95 8.1 Introduction The PPC-123's onboard audio interface provides high-quality stereo sound and FM music synthesis (ESFM) by using the ES1946S audio controller from ESS Technology, Inc. The audio interface can record, compress, and play back voice, sound, and music with a built-in mixer control.
  • Page 96 8.2.1 Installation for Windows 95/98 a. Select "Start", "RUN". Enter the driver path: "D:\ PPC123&153\ Audio\win9x(only)\ Setup.exe" a. Click "Next" to continue the installation. a. Select "Upgrade Drivers". Click "Next". a. When installation is completed, click "Finish" to restart your computer.
  • Page 97 a. After installation, select "Start", "Settings", "Control Panel", "System". Click the "Device Manager" tab to see the result of your installation. PPC-123 User's Manual...
  • Page 98 8.2.2 Installation for Windows NT a. Select "Start", "Settings", "Control Panel". Double Click the "Multimedia" icon. a. Select the "Devices", item. Click the "Add..." button. a. Choose the "Unlisted or Updated Driven" item. b. Click the "OK" buttom. a. Type the path "D:\ ppc123&153\audio\ nt40\ b.
  • Page 99 a. Slecte the highlighted item. b. Press the "OK" buttom. a. Press the "Restart Now" buttom to reboot your computer. 8.2.3 Installation for Windows 20000/ME After finishing the Windows 2000 or Windows ME installation, the system can automatically detect the audio hardwre and install the driver from the driver database in Windows 2000 or Windows ME when the system reboots.
  • Page 100 Award BIOS Setup This chapter describes how to set BIOS configuration data.
  • Page 101 This is because the BIOS is revised and updated from time to time. If in doubt, check Advantech's web site for the latest BIOS versions and related information. 9.2 CMOS Setup Utility Figure 9-1: Setup program initial screen...
  • Page 102 A setup program, built into the system BIOS, is stored in the CMOS RAM that allows the configuration settings to be changed. This program is executed when the user changes the system configuration; when the user changes the system backup battery; or when the system detects a configuration error and asks the user to run the setup program.
  • Page 103 9.3.1 Hard Disk Configurations TYPE Select from 1 to 45 to fill the remaining fields with predefined values for disk drives. Select "User" to fill the remaining fields. Select "Auto" to detect the HDD type automatically. SIZE Hard disk size. The unit is megabytes (MB). CYLS The cylinder number of the hard disk.
  • Page 104 9.4 BIOS Features Setup Figure 9-3: BIOS features setup screen Moving around the BIOS Features and Chipset Features setup programs works the same way as moving around the Standard CMOS setup program. (Refer to the next section for Chipset Features setup.) The BIOS Features setup program is shown above.
  • Page 105 External Cache When enabled, supports an external cache SRAM. The options are: Enabled (Default), Disabled. CPU L2 Cache ECC Checking Allows the CPU L2 cache to enable the memory parity check. The options are: Disabled (Default), Enabled. Quick Power On Self Test When enabled, allows the BIOS to bypass the extensive memory test.
  • Page 106 Swap Floppy Drive When enabled, allows you to switch the order in which the operating system accesses the floppy drives during boot-up. The options are: Disabled (Default), Enabled. Boot Up Floppy Seek When enabled, assigns the BIOS to perform floppy disk drive tests by issuing seek commands.
  • Page 107 The options are: Disabled (Default), Enabled. PCI/VGA Palette Snoop When enabled, allows you to install an enhanced graphics adapter card. If your graphics adapter card does not support the Palette Snoop function, set at "Disabled" to avoid system malfunctions. The options are: Disabled (Default), Enabled. OS Select For DRAM >...
  • Page 108 9.5 Chipset Features Setup Note: It is strongly recommended that setup items in this section NOT be changed, because advanced knowledge is required to effect such changes. Figure 9-4: Chipset features setup screen EDO CASX# MA Wait State Sets the EDO CASX# MA wait state. The options are: 1 (Default), 2.
  • Page 109 SDRAM Data Integrity Mode When set as Non-ECC, supports standard 64-bit DIMM RAM modules. When set as ECC, supports standard 72-bit ECC RAM modules. The options are: Non-ECC (Default), ECC. System BIOS Cacheable When enabled, allows the ROM area FOOOH-FFFFH to be cacheable when the cache controller is activated.
  • Page 110 Delayed Transaction When disabled, the syatem operates normally. When enabled, the system can support lower-speed ISA devices. The options are: Disabled (Default), Enabled. Spread Spectrum When disabled, the syatem operates normally. When enabled, the spread spectrum will be set to 0.5% (CNTR). The options are: Disabled (Default), Enabled.
  • Page 111 PM Control by APM The option "No" allows the BIOS to ignore the APM (Advanced Power Management) specification. Selecting "Yes" will allow the BIOS to wait for APM's prompt before it enters Doze mode, Standby mode, or Suspend mode. If the APM is installed, it will prompt the BIOS to set the system into power saving mode after all tasks are done.
  • Page 112 Standby Mode The system will not enter Standby mode, because this option is designated as "Disabled". Suspend Mode The system will not enter Suspend mode, because this option is designated as "Disabled". HDD POWER Down Selecting "Disabled" will turn off the hard disk drive (HDD) motor. Selecting "1 Min..
  • Page 113 9.7 PNP/PCI Configuration Setup Figure 9-6: PNP/PCI configuration setup screen PNP OS Installed Select Yes if the installed system supports the PnP function. Select No if the installed system does not support the PnP function. The options are: No (Default), Yes. Resources Controlled By If set at "Auto", the BIOS automatically arranges all system resources for you.
  • Page 114 The options are: Disabled (Default), Enabled. Used MEM base addr Choose and use the MEM base address. The options are: N/A (Default), C800 ~ DC00. Assign IRQ for USB Assigns an IRQ for the USB. The options are: Disabled (Default), Enabled. 9.8 Load BIOS Defaults Figure 9-7: Load BIOS defaults screen The BIOS defaults screen contains the most appropriate values of the...
  • Page 115 9.10 Integrated Peripherals Figure 9-8: Integrated peripherals screen IDE HDD Block Mode This allows your hard disk controller to use the fast block mode to transfer data to and from your hard disk drive (HDD). The options are: Enabled (Default), Disabled. IDE Primary/Secondary Master/Slave PIO IDE hard disk drive controllers can support up to separate hard drives.
  • Page 116 Your system supports five modes, numbered from 0 through 4, which differ primarily in timing. When "Auto" is selected, the BIOS will choose the best available mode. The options are: Auto, (Default), Disabled. Primary/Secondary Master/Slave Ultra DMA DMA means Direct Memory Access. Ultra DMA is faster than DMA. DMA is a method of transferring data to or from memory at a fast rate, without involving the CPU.
  • Page 117 The options are: 378/IRQ7 (Default), 3BC/IRQ7, 278/IRQ5, Disabled. Parallel Port Mode You can choose different data transfer modes for your system. The options are: ECP & EPP (Default), SPP, EPP, ECP. ECP Mode Use DMA You can choose different DMA modes for data transfer. The options are: 3 (Default), 1.
  • Page 118 9.12 IDE HDD Auto Detection Figure 9-9: IDE HDD auto detection screen The IDE Hard Disk Drive Auto Detection feature automatically configures your new hard disk. Use it for quick configuration of new hard disk drives. This feature allows you to set the parameters of up to four IDE HDDs.
  • Page 119 9.13 Save and Exit Setup Figure 9-10: Save and exit setup screen After you have made changes in the BIOS setup, press "Esc" to return to the main menu. Move the cursor to "Save and Exit Setup", or press "F10" and then press "Y", to change the CMOS Setup. If you did not change anything, press "Esc"...
  • Page 120 PCMCIA • Introduction • Installation of PCMCIA Driver - for Windows 95...
  • Page 121 10.1 Introduction The PPC-123 is equipped with a high performance PCMCIA interface which complies with the 1995 PCMCIA card standard by using the RICOH Cardbus controller. The panel PC supports two PCMCIA card/cardbus slots. Two sockets support both a 16-bit PCMCIA card and a 32-bit Cardbus simultaneously, with hot insertion and removal.
  • Page 122 10.2.1 Installation for Windows 95 a. In "Start", "Run", type the path: D:\ PPC123&153\ Cardbus\win95osr2\ Setup.exe a. Click "Next". a. Click "Yes". a. Click "Finish" to reboot the system. Chapter 10 PCMCIA...
  • Page 123 PPC-123 User's Manual...
  • Page 124 Touchscreen • Introduction • Installation of Driver for Resistive Touchscreen - for Windows 95 - for Windows 98 - for Windows NT - for Windows 2000 - for Windows ME • Installation of Driver for Capacitive Touchscreen - for Windows 95/98/NT...
  • Page 125 11.1 Introduction 11.1.1 General information The PPC-123's optional touchscreen incorporates advanced second-generation 5-wire resistive or impact-resistant capacitive technology. They allow 75% and 85% light transmission respective- ly and have an antiglare surface. All models provide greatly enhanced visual resolution. They also have new improved scratch-resistant features.
  • Page 126 the following chemicals when exposed for a period of one hour at a temperature of 21° C (71° F): - Acetone - Methylene chloride - Methyl ethyl ketone - Isopropyl alcohol - Hexane - Ammonia-based glass cleaners - Turpentine - Mineral spirits - Foods and beverages 11.2 Installation of Driver for Resistive Touch- screen...
  • Page 127 11.2.1 Installation for Windows 95 a. Insert the "Drivers and Utilities" CD. Click the "Start" button, and then "Run". c. Type the path "D:\ PPC123&153\ Elotouch\Win95\ Setup.exe". a. Click "Yes". a. Select the "Smart serial Controller on COM4" item. b. Press the "OK" buttom.
  • Page 128 a. Touch targets to calibrate the touchscreen controller. Chapter 11 Touchscreen...
  • Page 129 11.2.2 Installation for Windows 98 If you want to use the touchscreen driver CD-ROM accompanying your panel PC, refer to the following flow chart instructions. a. Insert the "Drivers and Utilities" CD. Click the "Start" button, and then "Run". c. Type the path "D:\ PPC123&153\ Elotouch\Win98\ Setup.exe".
  • Page 130 a. Touch targets to calibrate the touchscreen controller. Chapter 11 Touchscreen...
  • Page 131 11.2.3 Installation for Windows NT a. Select "Start", "Run". Type the path "D:\ PPC123&153\ Elotouch\WINNT\ Setup.exe" a. Press the "Next" button. a. Set the directory path. a. Choose a suitable item. PPC-123 User's Manual...
  • Page 132 a. Chose COM4. b. Press "OK". a. Click "OK" to reboot the System. a. Calibrate the touchscreen. Chapter 11 Touchscreen...
  • Page 133 11.2.4 Intallation for Windows 2000 a. Select "Start", "Run" Type the path "D:\ PPC123&153\ Elotouch\Win2k\ Setup.exe" Click "OK" a. Press "Next" a. Click "Yes" a. Select "Yes" to accept agreement PPC-123 User's Manual...
  • Page 134 a. Choose "COM4" Then click "Next" a. Press "Finish" Click "Yes" to reboot the system a. Calibrate the touch screen Chapter 11 Touchscreen...
  • Page 135 a. Click "Finish" to complete installation PPC-123 User's Manual...
  • Page 136 11.2.5 Installation for Windows ME a. Select "Start", "Run" Type the path"D:\ 123&153\Elotouch\ WInME\Setup.exe" c. Click "OK" a. Click "Next" a. Click "Yes" to accept the agreement. a. Press "Next" Chapter 11 Touchscreen...
  • Page 137 a. Choose "COM4" b. Press "Next" a. Calibrate the touch screen a. Click "Finish" to complete the installation PPC-123 User's Manual...
  • Page 138 11.3 Installation of Driver for Capacitive Touchscreen To facilitate installation of the touchscreen driver, you should read the instructions in this chapter carefully before you attempt installation. Important: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen.
  • Page 139 11.3.1 Installation for Windows 95/98/NT a. Select "Start", "Run". b. Type in: D:\ PPC123&153\ Microtouch\Tware54\ Setup.exe a. Follow the installation instructions, and click on "Next". a. If you accept the terms of the License Agreement, click on "Yes". a. Select the Serial [Default] controller.
  • Page 140 a. Select the "Express Install..." item. b. Click on "Next". a. Select the "Yes, ..." item to reboot the system and finish the touchscreen driver installation. a. Click on "Calibrate" to calibrate the touchscreen. b. Touch the "target point" for a moment, until the next "Touch enable"...
  • Page 141 PPC-123 User's Manual...
  • Page 142 LCD Specifications and Selection Settings...
  • Page 143 The color LCD display installed in the panel PC is high-quality and reliable. However, it may contain a few defective pixels which do not always illuminate. With current technology, it is impossible to complete- ly eliminate defective pixels. Advantech is actively working to improve this technology. PPC-123 User's Manual...
  • Page 144 Programming the Watchdog Timer The PPC-123 is equipped with a watch- dog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.
  • Page 145 B.1 Programming the Watchdog Timer To program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a time interval value. The value range is from 01 (hex) to 3E (hex), and the related time interval is from 1 sec.
  • Page 146 The following example shows how you might program the watchdog timer in BASIC: Watchdog timer example program OUT &H443, data REM Start and restart the watchdog GOSUB 1000 REM Your application task #1, OUT &H443, data REM Reset the timer GOSUB 2000 REM Your application task #2, OUT &H443, data REM...
  • Page 147 PPC-123 User's Manual...
  • Page 148 Full Disassembly Procedures...
  • Page 149 C.1 Full Disassembly Procedures If you want to completely disassemble the panel PC, follow the step-by-step procedures below. Users should be aware that Advantech Co., Ltd. takes no responsibility whatsoever for any problems or damage caused by the user disassembly of the panel PC. Make sure the power cord of the panel PC is unplugged before you start disas- sembly.
  • Page 150 Step 1 & Step 2 Step 4 Step 3 Figure C-1: Disassembly steps 1 - 4 Appendix C Full Disassembly Procedures...
  • Page 151 machine. The electric fan and power inlet can also be removed from the case by unscrewing the screws. 5. Unscrew the fourteen screws of the I/O bracket with a hexagonal screwdriver. The EMI protection cover lies below the I/O bracket. You can now remove both the bracket and the cover from the I/O ports.
  • Page 152 I/O bracket Step 5 protection cover Step 6 Motherboard Figure C-2: Disassembly steps 5 - 6 Appendix C Full Disassembly Procedures...
  • Page 153 7. Unscrew the four screws on the power supply board. The power supply board can be detached from the LCD holding plate after unplugging the two cables from the power inlet and motherboard. 8. Detach the LCD holding plate and LCD by unscrewing the four screws at the bottom.
  • Page 154 Power Step 7 supply Step 8 Backplane plate Step 9 Step 10 Touchscreen Step 11 Front panel Figure C-3: Disassembly steps 7 - 11 Appendix C Full Disassembly Procedures...
  • Page 155 PPC-123 User’s Manual...
  • Page 156 Pin Assignments • AT Power Connector (J1) • TV Output Connector (J2) (*Reserved) • Inverter Power Connector (J4) • Internal Speaker Connector (J6) • Front Panel Control Connector (J8) • IR Connector (J9) • Flat Panel Display Connector (CN2) • Flat Panel Display Connector (CN3) •...
  • Page 157 D.1 AT Power Connector (J1) Table D-1: AT power connector (J1) Signal PS_NO # +5 VSB +12 V -12 V -5 V +5 V +5 V +5 V D.2 TV Output Connector (J2) (*Reserved) Table D-2: TV output connector (J2) Signal CVBS PPC-123 User’s Manual...
  • Page 158 D.3 Inverter Power Connector (J4) Table D-3: Inverter power connector (J4) Signal +12 V ENABKL Brightness Adj. +5 V D.4 Internal Speaker Connector (J6) Table D-4: Internal speaker connector (J6) Signal Speaker out_R - Speaker out_R + Speaker out_L + Speaker out_L - Appendix D Pin Assignments...
  • Page 159 D.5 Front Panel Control Connector (J8) (*Reserved) Table D-5: Front panel control connector (J8) (*Reserved) Signal HDD LED Reset SW Power SW D.6 IR Connector (J9) Table D-6: IR connector (J9) (Reserved) Signal IR_IN IR_OUT PPC-123 User’s Manual...
  • Page 160 D.7 Flat Panel Display Connector (CN2) Table D-7: Flat panel display connector (CN2) Signal Signal VDDSAFE5 VDDSAFE5 VDDSAFE3 VDDSAFE3 Vcon SHFCLK M/DE ENABKL ENAVEE Appendix D Pin Assignments...
  • Page 161 D.8 Flat Panel Display Connector (CN3) Table D-8: Flat panel display connector (CN3) Signal Signal VDDSAFE5 VDDSAFE5 VDDSAFE3 VDDSAFE3 Vcon SHFCLK M/DE ENABKL ENAVEE PPC-123 User’s Manual...
  • Page 162 D.9 Panel Link Interface (CN4) (*Reserved) Table D-9: PanelLink Interface (CN4) (*Reserved) Signal Signal TXC- TX1+ TXC+ TX2- TX0- TX2+ EDGE TX0+ 2NDSDA TX1- 2NDSCL Appendix D Pin Assignments...
  • Page 163 D.10 Floppy Drive Connector (CN10) Table D-10: Floppy drive connector (CN10) Signal Signal (+5 V) STEP INDEX (+5 V) WRITE DATA DRIVE SELECT (+5 V) WRITE ENABLE DISK CHANGE TRACK 0 WRITE PROTECT MOTOR ON READ DATA DIRECTION DENSITY SELECT SIDE 1 SELECT PPC-123 User’s Manual...
  • Page 164 D.11 EIDE Hard Disk Drive Connector (CN16) Table D-11: EIDE hard disk drive connector (CN16) Pin Signal Signal IDE RESET # DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1...
  • Page 165 D.12 CD-ROM Connector (CN18) Table D-12: CD-ROM connector (CN18) Signal Signal Audio_L Audio_R IDE RESET # DATA8 DATA7 DATA9 DATA6 DATA10 DATA5 DATA11 DATA4 DATA12 DATA3 DATA13 DATA2 DATA14 DATA1 DATA15 DATA0 HDD DREQ IO READ IO WRITE HD READY HD ACK 0 # IRQ 15 ADDR1...
  • Page 166 D.13 CPU Fan Power Connector (FAN1) Table D-13: CPU fan power connector (FAN1) Signal +12 V FAN_DET D.14 System Fan Power Connector (FAN2) Table D-14: Fan power connector (FAN2) Signal +12 V FAN_DET Appendix D Pin Assignments...
  • Page 167 D.15 PCI/ISA Bus Expansion Connector (SLOT1) side view PPC-123 User’s Manual...
  • Page 168 Table D-15: PCI/ISA slot pin assignments (Pins A and B) Signal Signal IOCHK IRQ9 DRQ2 -12 V +12 V IORDY SA19 SA18 SA17 SA16 DACK3 SA15 DRQ3 SA14 DACK1 SA13 DRQ1 SA12 SA11 SCLK SA10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2 Appendix D Pin Assignments...
  • Page 169 Table D-16: PCI/ISA slot pin assignments (Pins C and D) Signal Signal SBHE MEM16 LA23 IO16 LA22 IRQ10 LA21 IRQ11 LA20 IRQ12 LA19 IRQ15 LA18 IRQ14 LA17 DACKO MEMR DRQ0 MEMW DACK5 DRQ5 DACK6 SD10 DRQ6 SD11 DACK7 SD12 DRQ7 SD13 SD14 MASTER...
  • Page 170 Table D-17: PCI/ISA slot pin assignments (Pins E and F) Signal Signal INT 1 INT3 INT 2 INT4 PCLK2 GNT2 REQ2 GNT3 PCLK1 REQ3 AD31 AD30 AD29 AD28 AD27 AD26 AD25 AD24 CBE3 AD22 AD23 AD20 AD21 AD18 AD19 AD16 AD17 FRAME IRDY...
  • Page 171 Table D-18: PCI/ISA slot pin assignments (Pins G and H) Signal Signal SERR AD15 CBE1 AD14 AD12 AD13 AD10 AD11 CBEO PPC-123 User’s Manual...
  • Page 172 D.16 Touchscreen Connector (CN23) Table D-19: Internal COM4 and PS/2 Connector (CN23) Signal Signal NRLSD NDSR NRTS NCTS NDTR MSDAT EXT MSDAT MSCLK EXT MSCLK D.17 COM2 Table D-20: COM2 Signal RS-232 RS-422 RS-485 DATA- DATA+ Appendix D Pin Assignments...
  • Page 173 PPC-123 User’s Manual...
  • Page 174 Mounting Instructions • Introduction • Panel Mounting • Desktop Stand Mounting • Swingarm Stand Mounting...
  • Page 175 E.1 Introduction The PPC-123 can be placed as is on a shelf or table, mounted into a panel, or mounted on a customized swingarm or desktop stand. E.2 Panel Mounting E.2.1 Introduction Panel mounting can help system integrators conveniently integrate the panel PC into their system.
  • Page 176 E.2.2 Installation procedure To mount the PPC-123 into a panel: 1. There are six plastic caps located along the four sides of the panel PC. Pry them off with a flat-head screwdriver. 2. Insert the fixation wedges into the holes and tighten them with the screws provided.
  • Page 177 A unique spring inside the stand enables the panel PC’s vertical tilt to be adjusted about 30 degrees. The stand is available from Advantech Co. Follow these procedures to set up the stand: 1. Remove the rear cover of the panel PC by unscrewing the seven screws.
  • Page 178 Rear cover of panel PC Holding plate Top cover Main body Rear cover Base Figure E-3: Desktop stand mounting Appendix E Mounting Instructions...
  • Page 179 Its dimensions are shown in Figure E-4 below, and it is available from Advantech Co., Ltd. Unit: mm Figure E-4: Swingarm stand mounting...
