PPC-105
NS GX1 processor-based Panel PC
with 10" TFT LCD flat panel display
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-105 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PPC-105

Summary of Contents for Advantech PPC-105

  • Page 1 PPC-105 NS GX1 processor-based Panel PC with 10” TFT LCD flat panel display User’s Manual...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted 2001 by Advantech Co. Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
  • Page 3 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.

  • Page 4: Packing List

    If any of these items are missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance 1. Visit the Advantech Web site at www.advantech.com where you can find the latest information about the product. 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.

  • Page 5: Safety Instructions

    The sound pressure level at the operator's position according to IEC 704-1:1982 is equal to or less than 70 dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 6 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70 dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.

  • Page 7: Table Of Contents

    Contents Chapter 1 General Information....... 1 1.1 Introduction ..............2 1.2 Specifications ............. 2 General ................... 2 Standard PC functions ............. 2 Solid State Disk (SSD) ............3 PCI SVGA/flat panel interface ..........3 Audio function: ................. 4 PCI bus Ethernet interface ............4 Touchscreen (optional) .............
  • Page 8 2.4.2 Installing an FDD ............18 2.4.3 Parallel port connection ..........19 2.4.4 PS/2 keyboard and PS/2 mouse ........19 2.4.5 Mic-in, line-out .............. 20 2.4.6 External VGA ..............20 2.4.7 Four serial COM ports ........... 20 2.4.8 Ethernet ................ 20 2.4.9 USB ports ..............
  • Page 9 4.2.1 Installation for WINDOWS 95 ........39 4.2.2 Installation for WINDOWS 98 ........42 4.2.3 Installation for WINDOWS NT ........43 4.3 Further Information ............ 48 Chapter 5 PCI SVGA Setup ......49 5.1 Introduction ..............50 5.1.1 Chipset ................. 50 5.1.2 Display memory ............
  • Page 10 7.8 Load BIOS Defaults ..........84 7.9 Load Setup Defaults ..........85 7.10 Integrated Peripherals ..........85 WDT Active When Power ON ..........87 7.11 Password Setting ............ 88 7.12 IDE HDD Auto Detection ......... 88 7.13 Save and Exit Setup ..........89 7.14 Exit Without Saving ..........
  • Page 11 Figure 1-1: PPC-105 panel PC dimensions ........... 6 Figure 1-2: PPC-105 back panel I/O arrangement and cable connections ................7 Figure 1-3: PPC-105 panel mounting cutout dimensions ...... 8 Figure 1-5: PPC-105 rear panel mounting brackets ......9 Figure 1-6: PPC-105 desktop stand ........... 10 Figure 1-7: PPC-105 wall mounting configuration ........
  • Page 12 Tables Table 1-1: PPC-105 series LCD specifications ........5 Table 3-1: Jumpers and their functions ..........29 Table 3-2: Panel PC Connectors ............30 Table 3-3: Wake-on-LAN selection ............. 33 Table 3-4: Clear CMOS/External RTC ..........33 Table 3-5: Watchdog activity selection ..........34 Table 3-6: COM2 RS-232/422/485 setting ...........

  • Page 13: Chapter 1 General Information

    GENERAL INFORMATION This chapter gives background information on the PPC-105. Sections include: • Introduction • Specifications • LCD Specifications • Dimensions • I/O Arrangement • Cutout (Suggestion) • Mounting...

  • Page 14: Introduction

    1.1 Introduction The PPC-105 is a 10" LCD Panel PC with an NS GX1 CPU that is designed to serve as a human machine interface (HMI). It is a PC- based system with 10" color TFT LCD display, on-board PCI Ethernet, multi-COM port interfaces, and a 16-bit audio controller.

  • Page 15: Solid State Disk (Ssd)

    • CPU: NS GX1 300 MHz processor on board 352 BGA package • BIOS: AWARD 256KB Flash BIOS, supports Plug & Play, APM v1.2 • Chipset: NS CX 5530 352-terminal BGA package • 2nd level cache: 16 KB on CPU •...

  • Page 16: Audio Function

    • Software driver: Supports DOS, Windows 95/98, Windows NTand Windows 2000 • Durability: 30 million touch lifetime **Note: The PPC-105 with the optionally installed touchscreen will share COM4. Environment • Temperature: 0° ~ 45° C (32° ~ 113° F) • Relative humidity: 10 ~ 95% @ 40 °C, non-condensing •...

  • Page 17: Lcd Specifications

    1.3 LCD Specification " 0 ° 0 ) ² ° Table 1-1: PPC-105 series LCD specifications Chapter 1 General Information...

  • Page 18: Dimensions

    1.4 Dimensions Unit: mm Figure 1-1: PPC-105 panel PC dimensions PPC-105 User's Manual...

  • Page 19: I/O Arrangement

    External IDE port l. Light indicator f. AC inlet m. Ethernet port g. Parallel port * Three RS-232 (COM1, 3, 4) and one RS-232/422/485 (COM2) Figure 1-2: PPC-105 back panel I/O arrangement and cable connections Chapter 1 General Information...

  • Page 20: Cutout (Suggestion)

    1.6 Cutout (Suggestion) The PPC-105 will stand on a shelf or a table, or you can mount it into a panel. Cutout panel dimensions are as follows: Cutout for panel mount Unit: mm Figure 1-3: PPC-105 panel mounting cutout dimensions...

  • Page 21: Mounting

    1.7 Mounting 1.7.1 Panel mounting If you decide to use a cutout within a panel to mount your PPC-105, we have included two panel-mount brackets. The brackets have two screws that fit in the keyhold slots on the panel PC.

  • Page 22: Desktop Stand (Optional)

    1.7.2 Desktop stand (optional) An optional stand is available for mounting the PPC as a desktop PC. The PPC-105 slides into the stand and is held in place by the screws provided. The compactness of the desktop-mounted PPC-105 saves desk space.

  • Page 23: Wall-Mounting (Optional)

    1. The wall-mounting attachment is comprised of three parts: one back bracket, one support bracket, and one mounting bracket. 2. First attach the back bracket to the rear cover of the PPC-105, securing it in place with four of the philips-head screws provided.
  • Page 24 PPC-105 User's Manual...

  • Page 25: Chapter 2 System Setup

    System Setup • General • Removing Rear Panel • Installing Options • Installing I/O Equipment • Installing Software to the HDD • Exploded Diagram • PCM-5821 and I/O Adapter Replacement • Power Supply and Cooling Fan Replacement...

  • Page 26: General

    Every time you service the PPC-105, you should be aware of this. 2.2 Preparing For First Time Usage Before you set up the PPC-105 system, you should have at least the following items ready: • Power cord (in the accessory box) •...

  • Page 27: Installing Options

    2.3 Installing Options 2.3.1 Removing Rear Panel Unscrew the eleven screws that secure the rear cover, then remove the cover. Figure 2-1: Removing the PPC-105's rear panel Chapter 2 System Setup...

  • Page 28: Installing A Primary 2.5" Hdd (Internal)

    2.3.2 Installing a primary 2.5" HDD (internal) You can attach one enhanced Integrated Device Electronics (IDE) hard disk drive to the PPC-105's internal controller which uses a PCI local- bus interface. The advanced IDE controller supports faster data transfer rates and allows the IDE hard drive to exceed 528 MB. The following are instructions for installation: 1.

  • Page 29: Figure 2-2: Installing A Primary 2.5" Hdd (Internal)

    Figure 2-2: Installing a primary 2.5" HDD (internal) Chapter 2 System Setup...

  • Page 30: Installing I/O Equipment

    Two connectors are located on the rear panel above the PPC-105's I/O output connectors. The 40-pin connector is for an external set of master and slave hard disks. Connect the single end of the appropriate cable to the PPC-105, and connect the two remaining ends to your hard disk(s). Warning! All warnings in Section 2.3.1 apply here.

  • Page 31: Parallel Port Connection

    "Halt On" selection. This allows no-keyboard operation in embedded system applications without the system halting under POST. Note that the mouse port on the PPC-105 is a PS/2 mouse port. * Note: "All, But keyboard" is the default setting.

  • Page 32: Mic-In, Line-Out

    (See Fig. 1-2). Their functions are: 2.4.6 External VGA The PPC-105 can be connected to an external CRT monitor. To connect an external CRT monitor, connect the monitor's VGA cable to the PPC-102's VGA port and connect the monitor's power cable to an AC outlet.

  • Page 33: Usb Ports

    2.5.3 Method 3: Use the COM or parallel port You can use Lap Link 6 or similar transmission software. Connect another PC to the PPC-105 with an appropriate cable and transmit the software to the PPC-105. 2.5.4 Method 4: Use a 3.5" HDD or CD-ROM Please refer to Section 2.4.1 "Installing one secondary HDD/CD-ROM...

  • Page 34: Exploded Diagram

    2. Install the driver before you use the device 2.6 Exploded Diagram Figure 2-3 shows all the components and parts taht make up the PPC- 105. Use it asa guide when assembling and disasesembling your system. Figure 2-3: PPC-105 exploded diagram PPC-105 User's Manual...

  • Page 35: Pcm-5821 And I/O Adapter Replacement

    To replace or service the PCM-5821 (the all-in-one CPU board) and I/O adapter, complete the following steps: 1. Turn off the power to the PPC-105 2. Remove the rear protective cover (see Figure 2-1) 3. Install the PCM-5821 in the panel and screw in the eight screws (see Figure 2-4) 4.
  • Page 36 PPC-105 User's Manual...

  • Page 37: Chapter 3 The Engine Of The Ppc-105T (Pcm-5821)

    The Engine of the PPC-105T (PCM-5821) • Introduction • Features • Jumpers and Connectors • Wake on LAN selction • CMOS clear • Watchdog timer configuration • COM2 RS-232/422/485setting • Buzzer enable...

  • Page 38: Introduction

    3.1 Introduction The PCM-5821 is a highly reliable single board computer based on the NS GX1 300MHz CPU. It offers built-in functionality comparable to a complete industrial PC system, including a VGA/LCD controller, network communications, compact flash diak in a small 8" x 5.75" form factor.

  • Page 39: Features

    3.2 Features • Ultra-compact size single board computer as small as a 3 1/2" hard disk drive (145 mm x 102 mm) • On-board NS GX1 300 MHz CPU • Up to 128 MB system memory by SODIMM (SDRAM) • On-board VGA/LCD controller •...

  • Page 40: Jumpers And Connectors

    3.3 Jumpers and Connectors 3.3.1 Setting jumpers You can configure your panel PC to match the needs of your applica- tion by setting jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 41: Jumpers

    3.3.2 Jumpers The motherboard of the panel PC has a number of jumpers that allow you to configure your system to suit your applications. The table below lists the function of each of the board jumpers. Table 3-1: Jumpers and their functions Label Function Power type of Lan...

  • Page 42: Connectors

    3.3.3 Connectors Onboard connectors link the panel PC to external devices such as hard disk drives or floppy drives. The table below lists the function of each of the board's connectors. Table 3-2: Panel PC connectors Label Function Inverter power connector Flat panel display connector Primary IDE hard drive connector Keyboard connector...

  • Page 43: Figure 3-1: Locating Jumpers And Connectors

    Power Fan Power test power connector connector (PS1) (CN6) Brightness VR(JS2) NS GX1 processor CPU Fan power I/O board connector connector (CN4) (CN8) Buzzer enable (JP10) CD IN connector (CN3) Chipset I/O board Cx5530 connector (CN5) Primary IDE Power type of Connector (J3) Lan (JP1) Figure 3-1: Locating jumpers and connectors on PCM-5821 (front side)

  • Page 44: Figure 3-2: Locating Jumpers And Connectors Pcm-5821 (Rear Side)

    COM2 RS-232/ SODIMM socket 422/485 Setting Inverter Power (CN1) Connector(J1) (JP3,JP4,JP5) Power Switch (CN10) CMOS clear and Watchdog Timer (JP2) Flat Panel Display Connector (J2) Speaker and Microphone connector (CN 20) Compact Flash Disk External secondary IDE KBT2 (CN7) Keyboard connector (CN2) connector Touchscreen...

  • Page 45: Wake On Lan Selection (Reserved) (Jp1)

    3.4 Wake on LAN Selection (Reserved) (JP1) The PCM-5821 provides Wake-on LAN function when ATX power is used. To enable Wake-on LAN function, the JP1 should be set as shown below: Table 3-3: Wake-on LAN selection (JP1) *Normal Power Wake-on LAN * default setting 3.5 CMOS Clear (JP2) Warning:...

  • Page 46: Watchdog Activity Selection (Jp2)

    3.6.1 Watchdog activity selection (JP2) When the watchdog timer activates (i.e. CPU processing has come to a halt), it can reset the system or generate an interrupt on IRQ11. This can be set via jumper JP2 as shown below: Table3-5: Watchdog activity selection (JP2) System reset IRQ11 * default setting...

  • Page 47: Buzzer Enable (Jp10)

    Table 3-7: COM2 RS-232/422/485 setting (JP5) *RS-232 RS-422 RS-485 *default setting 3.8 Buzzer enable (JP10) Table 3-8: Buzzer enable (JP10) *Enable Disable * default setting Chapter 3 The Engine of PPC-105T...
  • Page 48 PPC-105TUser's Manual...

  • Page 49: Chapter 4 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet Driver Installation for WINDOWS 95 - Installation for WINDOWS 98 Installation for WINDOWS NT • Further Information...

  • Page 50: Introduction

    4.1 Introduction The PPC-105T is equipped with a high performance 32-bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/ CD standards. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible. The medium type can be configured via the RSET8139.exe program included on the utility disk.

  • Page 51: Installation For Windows 95

    4.2.1 Installation for WINDOWS 95 1. a. Select "Start," "Settings" and "Control Panel" b. Click "Device Manager," "Other Devices" c. Remove "PCI Ethernet Controller" item 2. a. Select "Start", "Settings," "Control Panel" and "Network" b. Click "Add" Chapter 4 PCI Bus Ethernet Interface...
  • Page 52 3. Select "Adapter" and then click "OK" 4. Press "Have Disk..." 5. a. Type the path "D:\105\WIN95\LAN" b. Click "OK" D:\105\WIN95\LAN PPC-105T User's Manual...
  • Page 53 6. a. Select "Realtek RTL8139(A\B\C\8130) PCI Fast Ethernet" b. Click "OK" 7. Click "OK" Chapter 4 PCI Bus Ethernet Interface...

  • Page 54: Installation For Windows 98

    8. a. Insert "Win95" CD to load related file b. Click "OK" 9. Press "Yes" to start computer. 4.2.2 Installation for WINDOWS 98 Note that installation of the LAN drivers for Windows 98 is automatic and installation of the PCI Ethernet card is Plug-and-Play. No further instruction is necessary.

  • Page 55: Installation For Windows Nt

    4.2.3 Installation for WINDOWS NT 1. a. Select "Start," "Settings," "Control Panel" and double click "Network" b. Select from the list 2. Press "Have Disk..." Chapter 4 PCI Bus Ethernet Interface...
  • Page 56 3. a. Insert the "Drivers and Utilities" CD b. Enter the path "D:\105\WINNT\LAN" c. Press "OK" D:\105\WINNT\LAN 4. a. Choose "The TL8139 Fast Ethernet/Adapter" b. Click "OK" PPC-105T User's Manual...
  • Page 57 5. Click "Next" 6. Click "Next" Chapter 4 PCI Bus Ethernet Interface...
  • Page 58 7. Click "Next" 8. Click "Next" PPC-105T User's Manual...
  • Page 59 9. a. Insert "WINNT" CD b. Click "Continue" 10. Click "Next" Chapter 4 PCI Bus Ethernet Interface...

  • Page 60: Further Information

    11. Click "Next" 4.3 Further Information Realtek web site: www.realtek.com.tw Advantech web site: www.advantech.com www.advantech.com.tw PPC-105T User's Manual...

  • Page 61: Chapter 5 Pci Svga Setup

    PCI SVGA SETUP • Introduction • Installation of SVGA Driver - Installation for Windows 95 - Installation for Windows 98 - Installation for Windows NT • Further Information...

  • Page 62: Introduction

    5.1.3 Display types CRT and panel displays can be used simultaneously. The PPC-105 can be set in one of three configurations: on a CRT, on a flat panel display, or on both simultaneously. The system is initially set to simultaneous display mode.
  • Page 63 Note2: The CD-ROM drive is disgnated as "D" throughout this chapter. Note3: <Enter> means pressing the "Enter" keyon the keyboard. Chapter 5 PCI SVGA Audio Setup...

  • Page 64: Installation For Windows 95

    5.2.1 Installation for Windows 95 1. a. Select "Start," "Settings," "Contol Panel," "Display," "Settings" b. Press "Advanced Properties" 2. a . Choose "Adapter" tab b. Press the "Change..." button PPC-105 User's Manual...
  • Page 65 3. Press the "Have Disk" button. 4. a. Insert the utility disk into the CD-ROM drive b. Type "D:\105\WIN95\VGA" c. Press "OK" D:\105\WIN95\VGA 5. a. Select the highlighted "Control Panel" item b. Click the "OK" button. Chapter 5 PCI SVGA Audio Setup...
  • Page 66 6. a. Cyrix Xpress Graphics ™ appears in the adapter tab b. Click "Apply" and then "OK" 7. Press "close" PPC-105 User's Manual...
  • Page 67 8. Press "Yes" to reboot Chapter 5 PCI SVGA Audio Setup...

  • Page 68: Installation For Windows 98

    5.2.2 Installation for WINDOWS 98 1. Click the EXE file 2. Press "Finish" 3. Press "Next" PPC-105 User's Manual...
  • Page 69 4. Click "Yes" 5. a. Insert "Windows 98 CD-ROM" b. Click "Next" Chapter 5 PCI SVGA Audio Setup...
  • Page 70 7. Click "Finish" to complete installation Note: A common driver for Windows98 is used on both SVGA and Audio. While installing the SVGA driver for Windows98, as seen in the above procedure, the Audio driver will also be installed simultaneously. simultaneously.v PPC-105 User's Manual...

  • Page 71: Installation For Windows Nt

    5.2.3 Installation for WINDOWS NT 1. a. Select "Start," "Settings," "Control Panel" b. Double click "Display" c. Choose the "Settings" tab d. Press "Display Type" 2. Press "Change..." Chapter 5 PCI SVGA Audio Setup...
  • Page 72 3. Click "Have Disk" 4. a. Insert the disk into the CD-ROM drive b. Type the driver path "D:\105\WINNT\VGANT" c. Press "OK" D:\105\WINNT\VGANT 5. a. Select the highlighted item b. Press "OK" PPC-105 User's Manual...

  • Page 73: Further Information

    Click "Test" to see the result d. Click "OK" 5.3 Further Information For further information about the PCI/SVGA and audio installation in your PPC-105, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: NS web site: www.nsc.com Advantech web sites: www.advantech.com...
  • Page 74 PPC-105 User's Manual...

  • Page 75: Chapter 6 Audio Setup

    AUDIO SETUP • Introduction • Installation of Audio Driver - Installation for Windows 95 - Installation for Windows 98 - Installation for Windows NT • Further Information...

  • Page 76: Introduction

    You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. Note 2: The CD-ROM drive is designated as "D" throughout this chapter. Note 3: <Enter> means pressing the "Enter" key or the keyboard. PPC-105 User's Manual...

  • Page 77: Installation For Windows 95

    6.2.1 Installation for Windows 95 1. a. Remove "PCI Multimedia Audio Device" and "Unknown Device" from Device Manager b. Click "Close" 2. Click "Add new hardware" and "Next" 3. Select "No" and then click "Next" Chapter 6 PCI SVGA Audio Setup...
  • Page 78 4. a. Choose "Sound, video and game controllers" b. Click "Next" 5. Press "Have Disk" 6. a. Click "Add new hardware" and "Next" b. Enter "D:\105\WIN95\Audio" c. Click "OK" D:\105\WIN95\Audio PPC-105 User's Manual...
  • Page 79 7. a. Select "Xpress Audio™ 16-bit sound" b. Press "OK" 8. Click "Finish" 9. a. Insert "Win95" CD to load related files b. Click "OK" Chapter 6 PCI SVGA Audio Setup...

  • Page 80: Installation For Windows Nt

    The audio driver is automatically installed after the VGA driver is installed. Further installation information is not needed. 6.2.3 Installation for WINDOWS NT 1. a. Select "Start," "Settings," "Control Panel" b. Double click "Multimedia" 2. a. Select "Devices" b. Click "Add..." PPC-105 User's Manual...
  • Page 81 3. a. Choose "Unlisted or Updated Driver" b. Click "OK" 4. a. Insert "Drivers and Utilities" CD-ROM b. Enter the path "D:\105\WINNT\Audio" c. Click "OK" D:\105\WINNT\Audio 5. a. Select the highlighted item b. Press "OK" Chapter 6 PCI SVGA Audio Setup...
  • Page 82 6. Click "Continue" 7. a. Change MPU 40 O/O address to disable by pull down window b. Press "OK" 8. Press "Restart Now" PPC-105 User's Manual...

  • Page 83: Further Information

    6.3 Further Information For further information about the audio installation in your PPC-105, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: NS web site: www.nsc.com Advantech web site: www.advantech.com www.advantech.com.tw Chapter 6 PCI SVGA Audio Setup...
  • Page 84 PPC-105 User's Manual...

  • Page 85: Chapter 7 Award Bios Setup

    Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 86: Award Bios Setup

    7.1 Award BIOS Setup The PPC-105 comes with an Award BIOS chip that contains the ROM setup for your system. This chip serves as an interface between the processor and the rest of the mainboard's components. This chapter explains the information contained in the setup program and tells you how to modify the settings according to your system configuration.

  • Page 87: Standard Cmos Setup

    A setup program, built into the system BIOS, is stored in the CMOS RAM that allows the configuration settings to be changed. This program is executed when the user changes the system configuration; when the user changes the system backup battery; or when the system detects a configuration error and asks the user to run the setup pro- gram.

  • Page 88: Hard Disk Configurations

    LBA mode, select "LBA" or "Large". However, if your hard disk supporting cylinder is more than 1024 MB and does not support the LBA function, you have to select "Large". If your hard disk supporting cylinder is below 1024 MB, select "Normal". PPC-105 User's Manual...

  • Page 89: Bios Features Setup

    7.4 BIOS Features Setup Figure 7-3: BIOS features setup screen Moving around the BIOS Features and Chipset Features setup pro- grams works the same way as moving around the Standard CMOS setup program. (Refer to the next section for Chipset Features setup.) The BIOS Features setup program is shown above.
  • Page 90 Memory Parity Check The options are: Disabled (Default), Enabled. Typematic Rate Setting The term typematic means that when a keyboard key is held down, the character is repeatedly entered until the key is released. When this item PPC-105 User's Manual...
  • Page 91 is enabled, you may change the typematic repeat rate. The options are: Disabled (Default), Enabled. Typematic Rate (Chars/Sec) Sets the rate of a character repeat when the key is held down. The options are: 6 (Default), 8, 10, 12, 15, 20, 24, 30. Typematic Delay (msec) Sets the delay time before a character is repeated.

  • Page 92: Chipset Features Setup

    When enabled, allows the system to use the CPU build-in audio function. The options are: Enabled (Default), Disabled. If enable build-in CPU audio , go on the other audio settings . Audio I/O Base Address: 220H(Default), 240H, 260H and 280H. PPC-105 User's Manual...

  • Page 93: Power Management Setup

    Audio IRQ Select: Disable, IRQ 5, IRQ 7, IRQ 10. Audio Low DMA Select: Disable, DMA 0, DMA 1, DMA 3. Audio High DMA Select: Disable, DMA 5, DMA 6, DMA 7. Video Memory Size The video memory size is set by the manufacturer, depend on how many video memory on board.
  • Page 94 The options are: Enabled, Disabled. The default values of IRQ3, 4, 5, 6, 7, 9, 10, 11, 12, 13, 14, 15 are all: Enabled. The default value of IRQ8 is: Disabled. Note: Under certain operating systems such as WIN- PPC-105 User's Manual...

  • Page 95: Pnp/Pci Configuration Setup

    DOWS NT 4.0 (Build 1381), the CD auto-insertion feature might have some effect on power manage- ment. It is recommended that the CD-ROM drive use the secondary channel, and that the following Power Management Setup features be set: HDD & FDD: Off IRQ15 (Reserved): Secondary 7.7 PNP/PCI Configuration Setup Figure 7-6: PNP/PCI configuration setup screen...

  • Page 96: Load Bios Defaults

    When enabled, your system will be able to boot up through the Ethernet. The options are: Disabled (Default), Enabled. 7.8 Load BIOS Defaults Figure 7-7: Load BIOS defaults screen The BIOS defaults screen contains the most appropriate values of the system parameters that allow minimum system performance. PPC-105 User's Manual...

  • Page 97: Load Setup Defaults

    7.9 Load Setup Defaults Selecting this field loads the factory defaults for BIOS and Chipset Features. The system will automatically detect these defaults. 7.10 Integrated Peripherals Figure 7-8: Integrated peripherals screen Chapter 8 Award BIOS Setup...
  • Page 98 When you select "Auto", the BIOS will choose the best available mode. The options are: Auto (Default), Disabled. KBC input clock Set the keyboard cpntroller input clock. The options are: 6MHz, 8MHz, 12MHz, 16MHz Onboard FDD Controller When enabled, the floppy disk drive (FDD) controller is activated. PPC-105 User's Manual...

  • Page 99: Wdt Active When Power On

    The options are: Enabled (Default), Disabled. WDT Active When Power ON This is Advantech's patented watchdog function which can reboot the system should the computer hang in the BIOS checkup. The options are: 62 sec (Default), Disabled, 31 sec, 15 sec.

  • Page 100: Password Setting

    BIOS. You may also key in your own parameters instead of setting them according to the system BIOS. After keying in all settings, press "Esc" to return to the main menu. For confirmation, enter the Standard CMOS Setup feature. PPC-105 User's Manual...

  • Page 101: Save And Exit Setup

    7.13 Save and Exit Setup Figure 7-9: Save and exit setup screen After you have made changes in the BIOS setup, press "Esc" to return to the main menu. Move the cursor to "Save and Exit Setup", or press "F10" and then press "Y", to change the CMOS Setup. If you did not change anything, press "Esc"...
  • Page 102 PPC-105 User's Manual...

  • Page 103: Chapter 8 Touch Screen

    Touch Screen • Introduction • Installation of Driver for Resistive Touch Screen - for Windows 95 - for Windows 98 - for Windows NT - for Windows 2000 • Installation of Driver for Capacitive Touch Screen - for Windows 95/98/NT - for Windows 2000...

  • Page 104: Introduction

    8.1 Introduction 8.1.1 General information The PPC-105's optional touch screen incorporates advanced second-generation 5-wire resistive technology. They allow 75% light transmission. The resistive model has an antiglare surface. All models provide greatly enhanced visual resolution. They also have new improved scratch-resistant features.

  • Page 105: Installation Of Driver For Resistive Touch Screen

    8.2 Installation of Driver for Resistive Touch Screen The touch screen driver for Windows 95/98 contains a native, 32-bit driver and a 32-bit control panel program for the PPC-105 system. To facilitate installation of the touch screen driver, you should read the instructions in this section carefully before you attempt installation.
  • Page 106 1. a. Insert the “Driveres and Utilities” CD b. Click the “Start” button and then “Run.” c. Type the path “D:\105\Win95\Elotouch\Setup.exe” D:\105\Win95\Elotouch\Setup.exe 2. Click “Yes”. 3 a. Select the “SmartSet Serial Controller on COM4” item. b. Press “OK” PPC-105 User's Manual...
  • Page 107 4. Click the “Yes” button to restartyour computer. 5. Touch targets to calibrate the touch screen controller. Chapter 8 Touch screen 95...
  • Page 108 1.a. Insert the “Drivers and Utilites” CD. b. Click the “Start” button and then “Run” c. Type the path “D:\105\Win98\Elotouch\Setup.exe” D:\105\Win98\Elotouch\Setup.exe 2. Click “Yes” 3. a. Select the “SmartSet Serial Controller on COM4” item. b. Press the “OK” button. PPC-105 User's Manual...
  • Page 109 4. Click the “Yes” button to restartyour computer. 5. Touch target to calibrate the touch screen controller. Chapter 8 Touch screen 97...
  • Page 110 8.2.3 Installation for Windows NT 1. a. Select "Start" and "Run" b. Type the path "D:\105\WINNT\Elotouch\Setup.exe" D:\105\WINNT\Elotouch\Setup.exe 2. Press the "Next" button. 3. Set the directory path. PPC-105 User's Manual...
  • Page 111 4. Choose a suitable item. 5. a. Choose “COM4” b. Press “Next” 6. Click “Finish” to restart your computer. Chapter 8 Touch screen 99...
  • Page 112 7. Calibrate the touch screen. PPC-105 User's Manual...
  • Page 113 8.2.4 Installation for Windows 2000 1. Click “D:\105\Win2K\Elotouch\Setup” 2. Click “Next” 3. Click “Yes” Chapter 8 Touch screen 101...
  • Page 114 4.a. Select “COM4” b. Click “Next” 5. Click “Yes” PPC-105 User's Manual...
  • Page 115 6. Click “Finish” 7. a. Click “Yes” b. After the system reboots, click “Finish” to complete the installation. Chapter 8 Touch screen 103...
  • Page 116 PPC-105 User's Manual...

  • Page 117: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PPC-105 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for whatever reason. This feature ensures system reliability in industrial stand-alone or unmanned environments.

  • Page 118: Programming The Watchdog Timer

    REM Your application task #2 OUT &H443, data REM Reset the timer X=INP (&H443) REM Disable the watchdog timer 1000 REM Subroutine #1, you application task 1070 RETURN 2000 REM Subroutine #2, you application task 2090 RETURN 106 PPC-105 User's Manual...

  • Page 119: Appendix B Power Supply Specifications

    POWER SUPPLY SPECIFICATIONS • Introduction • Input Specifications • Output Specifications • Mechanical Specifications • Environmental Specifications • Features...

  • Page 120: Introduction

    B.1 Introduction The power supply of the PPC-105 is a 60 W double output, universal input switching power supply. It has been designed for medical technology applications. B.2 Input Specifications • Input voltage: 100 V to 250 V • Input frequency: 50 Hz to 60 Hz at AC input •...

  • Page 121: Environmental Specifications

    B.4 Environmental Specifications Operating temperature: 0 ~ 50° C, rated load Storage temperature: -40 ~ 85° C B.5 Features Efficiency: Higher than 70% (typical) while measuring at nominal line and rated load. Hold up time: Longer than 16 ms at 115 V input and rated load, which is measured from the end of the last charging pulse to when the main output drops down to 95% output voltage.
  • Page 122 PPC-105 User's Manual...

  • Page 123: Appendix C I/O Pin Assignments

    I/O Pin Assignments...

  • Page 124: Keyboard Connector (Cn5-1)

    C.1 Keyboard connector (CN5-1) Table C-1: Keyboard connector Signal KB_DT +5 V KB_CK C.2 Mouse connector (CN5-2) Table C-2: Mouse connector Signal MS_DT +5 V MS_CK PPC-105 User's Manual...

  • Page 125: Vga Connector (Cn6)

    C. 3 VGA connector (CN6) Table C-3: VGA connector Signal GREEN BLUE HSYNC VSYNC C.4 COM1 RS-232 serial port (CN1-2) Table C-4: COM1 RS-232 serial port Signal Appendix C I/O Pin Assignments...

  • Page 126: Com3 Rs-232 Serial Port Connector (Cn2-1)

    C.5 COM3 RS-232 serial port connector (CN2-1) Table C-5: COM3 RS-232 serial port Signal C.6 COM4 RS-232 serial port connector (CN2-2) Table C-6: COM4 RS-232 serial port Signal PPC-105 User's Manual...

  • Page 127: Com2 Connector

    C.7 COM2 Connector Table C-7: COM2 Signal RS-232 RS-422 RS-485 DATA- DATA+ Appendix C I/O Pin Assignments...

  • Page 128: Parallel Port Connector (Cn1-1)

    C.8 Parallel port connector (CN1-1) Table C-8: Parallel port connector Signal STROBE* ACK* BUSY SLCT AUTOFD* ERR* INIT* SLCTINI* * active low PPC-105 User's Manual...

Table of Contents
