5.2.1

Welding parameter setting

During the welding parameter setting process, the parameter value being set is displayed on the left-hand
display. The right-hand display shows the "Factory setting" or a variation of it upwards or downwards.
Displays, e.g. when setting the ignition current, and their meanings:
Display
5.2.2

Setting the welding current (absolute/percentage)

The welding current for the ignition, secondary, end and hot start current can be set as a percentage of
the main current AMP or as an absolute value. To select the display use the parameter
guration menu <dg _ref_source_inline>Gerätekonfigurationsmenü</dg_ref_source_inline>.
> see 5.13 chapter
099-000109-EW501
23.08.2018
Meaning of the symbols shown in the right-hand display
Increase parameter value
Factory setting Parameter value is on the optimum setting
Reduce parameter value
Design and function
To restore the factory settings.
To restore the factory settings.
TIG welding
in the confi-
