Design and function
Welding torch (operating variants)
Up/down torch with two torch triggers
Figure
Functions
Welding current on/off
Secondary current
Secondary current (tapping function)
Increase welding current (up function
Decrease welding current (down function
Welding current on/off
Secondary current
Secondary current (tapping function
Program selection upwards
Program selection downwards
Welding current on/off
Secondary current
Secondary current (tapping function
Increase welding current via current jump
Decrease welding current via current jump
Gas test
1
> see 5.8.1 chapter
2
> see 5.8.3 chapter
3
> see 5.8.4 chapter
84
Operating ele- Explanation of symbols
ments
BRT 1 = torch trigger 1 (left)
BRT 2 = torch trigger 2 (right)
1
/(latched operation)
2
)
2
)
1
)
1
)
3
3
Mode Operating ele-
ments
1
(ex works)
2
4
4
099-000109-EW501
> 3 s
23.08.2018
