Approved coolants overview

Coolant
KF 23E (Standard)
KF 37E
5.1.5.2

Maximal hose package length

All information relates to the total hose package length of the complete welding system and presents
exemplary configurations (of components of the EWM product portfolio with standard lengths). A straight
kink-free installation is to be ensured, taking into account the max. delivery height.
Pump: Pmax = 3,5 bar (0.35 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
Pump: Pmax = 4.5 bar (0.45 MPa)
--------------------------------------------------------------------------------------------------------------------- ►
Power source
Compact
Decompact
5.1.5.3

Adding coolant

The unit is supplied ex works with a minimum level of coolant.
Item Symbol
1
30
Hose package
(20 m / 65 ft.)
(25 m / 82 ft.)
(15 m / 49 ft.)
Hose package
(30 m / 98 ft.)
(40 m / 131 ft.)
(40 m / 131 ft.)
Description 0
Coolant tank cap
Temperature range
-10 °C up to +40 °C (14 °F up to +104 °F)
-20 °C up to +30 °C (-4 °F up to +86 °F)
Wire feeder miniDrive
(25 m / 82 ft.)
(10 m / 32 ft.)
Wire feeder miniDrive
(25 m / 82 ft.)
(25 m / 82 ft.)
Figure 5-1
Welding torch Max.
(5 m / 16 ft.)
(5 m / 16 ft.)
30 m
98 ft.
(5 m / 16 ft.)
(5 m / 16 ft.)
Welding torch Max.
30 m
98 ft.
(5 m / 16 ft.)
40 m
131 ft.
(5 m / 16 ft.)
45 m
147 ft.
(5 m / 16 ft.)
70 m
229 ft.
(5 m / 16 ft.)
