8.2

Tetrix 451 AC/DC

Welding current (I
Welding voltage according to Standard (U
Duty cycle at 40° C
80 %
100 %
Open circuit voltage (U
Mains voltage (Tolerance) / Frequency
[2]
Mains fuse
Mains connection cable
max. Connected load (S
Generator rating (Rec.)
max. Maximum mains impedance (@PCC)
Cos φ / Efficiency
Protection class / Overvoltage category
Contamination level
Insulation class / Protection classification
Residual current circuit breaker
[4]
Noise level
Cooling capacity at 1 l/min (+25°C/77°F)
max. Flow rate
max. Delivery height
max. Pump pressure
Pump / Tank content
Ambient temperature
Machine cooling
Torch cooling
Workpiece lead (min.)
EMC class
Safety marking
Standards used
Dimensions L / B / H
Weight
[1]
Load cycle: 10 min. (60 % DC = 6 min. welding, 4 min. pause).
[2]
DIAZED xxA gG safety fuses are recommended. When using automatic circuit-breakers, the "C" trig-
ger characteristic must be used!
[3]
This welding equipment does not comply with IEC 61000-3-12. When connecting a welding machine
to a public low-voltage supply system, the manufacturer or operator has to consult the electricity utili-
ties to make sure the welding machine may be connected.
[4]
Noise level during idle mode and operation under standard load according to IEC 60974-1 at maxi-
mum operating point.
[5]
Ambient temperature is dependent on coolant! Observe coolant temperature range!
099-000109-EW501
23.08.2018
)
2
2
[1]
)
0
)
1
[5]
TIG
) 10,2 V up to 28,0 V
3 x 400 V (-25 % up to +20 %) / 50/60 Hz
3 x 25 A
16,3 kVA
Type B (recommended)
5 l/min / 1.3 gal./min
Centrifugal pump / 12 l (2,65 gal.)
-25 °C up to +40 °C
See declaration of conformity (appliance documents)
1085 x 680 x 1204 mm / 42.7 x 26.8 x 47.4 inch
Technical data
Tetrix 451 AC/DC
MMA
5 A up to 450 A
20,2 V up to 38,0 V
450 A
420 A
79 V
3 x 32 A
H07RN-F4G6
22,0 kVA
30,0 kVA
[3]
xxx
0,99 / 85 %
Ⅰ / Ⅲ
3
H / IP 23
<70 dB(A)
1500 W
35 m / 115 ft.
3,5 bar / 0.35 MPa
Fan (AF)
Gas or water
2
70 mm
A
/ /
181,5 kg / 400.1 lb
