9.3.2

Tetrix 451-551 AC/DC

Type
ON Filter Tetrix XL
ON Holder Gas Bottle <50L
TETRIX XL
9.4

General accessories

Type
DM 842 Ar/CO2 230bar 30l D
GH 2X1/4'' 2M
32A 5POLE/CEE
ADAP 8-5 POL
9.5

Simultaneous welding on both sides, synchronisation types

9.5.1

Synchronisation via cable (frequency 50Hz to 200Hz)

For simultaneous, two-sided welding according to the master/slave principle, both welding
machines must be fitted with the 19-pole connection socket (ON 19POL) (Note different retrofitting
options depending on the machine type).
Type
SYNINT X10 19POL
RA10 19POL 10m
9.5.2

Synchronisation via mains voltage (50Hz / 60Hz)

Type
ON Netsynchron 351/451/551 Optional retrofit set for phase sequence changeover
9.6

Computer communication

Type
PC300.Net
099-000109-EW501
23.08.2018
Designation
Retrofit option, dirt filter for air inlet
Optional retrofit holding plate for gas cylinder <50l
Designation
Pressure regulator with manometer
Gas hose
Machine plug
8 to 5-pole adapter
Designation
Synchronisation set incl. interface and connector
cable
Remote control e.g. connection cable
Designation
for synchronous welding
Designation
PC300.Net welding parameter software kit incl.
cable and SECINT X10 USB interface
Accessories
General accessories
Item no.
092-004999-00000
092-002345-00000
Item no.
394-002910-00030
094-000010-00001
094-000207-00000
092-000940-00000
Item no.
090-008189-00000
092-001470-00010
Item no.
090-008212-00000
Item no.
090-008777-00000
111
