Conversion instructions
Retrofit option
ON NETSYNCHRON
GB
Observe additional system documents!
099-008212-EW501
14.03.2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tetrix 351 AC/DC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EWM Tetrix 351 AC/DC

Summary of Contents for EWM Tetrix 351 AC/DC

  • Page 1 Conversion instructions Retrofit option ON NETSYNCHRON Observe additional system documents! 099-008212-EW501 14.03.2011...
  • Page 2 © EWM HIGHTEC WELDING GmbH · Dr. Günter-Henle-Str. 8 · D-56271 Mündersbach, Germany The copyright to this document remains the property of the manufacturer.

  • Page 3: Table Of Contents

    3 Conversion ............................. 6 Parts list ............................7 Installing the PCB .......................... 8 3.2.1 Tetrix 351 AC/DC ......................8 3.2.2 Tetrix 451, 551 AC/DC ....................11 Installing the rotary switch at the back of the machine ..............13 4 Final inspection............................ 14 5 Appendix ...............................

  • Page 4: Overview

    Overview For your safety Overview For your safety DANGER Do not carry out any unauthorised repairs or modifications! To avoid injury and equipment damage, the unit must only be repaired or modified by specialist, skilled persons! The warranty becomes null and void in the event of unauthorised interference. •...

  • Page 5: Proper Usage

    Overview Proper usage Proper usage WARNING Hazards due to improper usage! Hazards may arise for persons, animals and material objects if the equipment is not used correctly. No liability is accepted for any damages arising from improper usage! • The equipment must only be used in line with proper usage and by trained or expert staff! •...

  • Page 6: Conversion

    Conversion Short description of the working steps required Conversion DANGER Risk of injury from electric shock! Servicing machines that are not disconnected from the mains can lead to serious injuries! • Disconnect the machine completely from the mains. • Unplug the mains plug! •...

  • Page 7: Parts List

    Conversion Parts list Parts list NOTE Before conversion, check that the retrofit kit is complete (see parts list). Tetrix 351 AC/DC as an example: Figure 3-1 Item 0 Quantity Description Item number PCB TSYN1 040-000676-00000 Flat band cable D-SUB 094-007494-00002...

  • Page 8: Installing The Pcb

    Conversion Installing the PCB Installing the PCB • Unscrew right-hand casing cover. • Remove the earth cable from the cover plate. 3.2.1 Tetrix 351 AC/DC Figure 3-2 Item 0 Quantity Description Item number PCB WK 6 D-SUB cable • Remove the D-SUB cable from the WK 6 PCB.
  • Page 9 Conversion Installing the PCB Figure 3-4 Item 0 Quantity Description Item number PCB WK 6 • Attach the D-SUB connection of the flat band cable to the WK6-X5 PCB and screw tight. Figure 3-5 Item 0 Quantity Description Item number PCB holder 094-016978-00000 Thread bolt M4 x 8 mm...
  • Page 10 Conversion Installing the PCB Figure 3-6 Item 0 Quantity Description Item number Rotary switch (assembly) 092-008178-00000 Flat band cable 094-000003-00000 Toroidal ferrite core (interference suppression) 034-000157-00000 Cable binder 044-001275-00000 Earthing cable (PE) 094-016979-00000 • Insert the flat band cable connector plug through the toroidal ferrite core and secure using a cable binder.

  • Page 11: Tetrix 451, 551 Ac/Dc

    Conversion Installing the PCB 3.2.2 Tetrix 451, 551 AC/DC TSYN1-X1 TSYN1-X2 Figure 3-7 Item 0 Quantity Description Item number M4 expanding anchor 094-006502-00000 PCB holder 094-016978-00000 Spacer M4 x 35 mm 044-002151-00000 Edge protection 094-007643-00000 Spacer 064-000567-00000 PCB TSYN1 040-000676-00000 Flat band cable D-SUB 094-007494-00002 •...
  • Page 12 Conversion Installing the PCB TSYN1-X3 TSYN1-PE Figure 3-8 Item 0 Quantity Description Item number Rotary switch (assembly) 092-008178-00000 Flat band cable 094-000003-00000 Toroidal ferrite core (interference suppression) 034-000157-00000 Cable binder 044-001275-00000 Earthing cable (PE) 094-016979-00000 • Insert the flat band cable connector plug through the toroidal ferrite core and secure using a cable binder.

  • Page 13: Installing The Rotary Switch At The Back Of The Machine

    Conversion Installing the rotary switch at the back of the machine Installing the rotary switch at the back of the machine Figure 3-9 Item 0 Quantity Description Item number Blind plug Rotary switch (assembly) 092-008178-00000 Oval-head screw M3x10 044-001414-00001 Adhesive film (rotary switch) 094-009599-00000 •...

  • Page 14: Final Inspection

    Final inspection Installing the rotary switch at the back of the machine Final inspection DANGER Protective earth PE! To protect persons and animals against dangerous live voltages and electric shocks in the event of a fault, the casing panels on the unit are connected to a green/yellow protective earth.

  • Page 15: Appendix

    Appendix Circuit diagram Appendix Circuit diagram X8/2 D-Sub. D-Sub. D-Sub. D-Sub. 15polig 15polig 15polig 15polig 099-008212-EW501 14.03.2011...

This manual is also suitable for:

Tetrix 451 ac/dcTetrix 551 ac/dc
