Load in Watt (active power)
Battery voltage / DC discharging current
Battery voltage / inverter internal temperature and solar
charge controller internal temperature
(Inverter temperature and solar charge controller
temperature is displayed in turns)
www.phocos.com
When load power is lower than 1 kW, active power is
shown in W (ex. 900 W)
When load power is lower than 1 kW, active power is
shown in kW (ex. 4.00 kW)
Battery voltage = 50 Vdc,
discharging current = 25 Adc
Battery voltage = 50 Vdc,
inverter temperature = 25 °C
Battery voltage = 50 Vdc,
solar charge controller temperature = 25 °C
35 |
P a g e
